Belden 2413 010U, CAT6+ 4 Pair U/UTP Plenum CMP 23 AWG, Black Jacket
Description
Belden 2413 010U is a Category 6+ enhanced premise horizontal cable (350MHz) with 4 pairs of 23 AWG solid bare copper conductors in a U/UTP design. It features a Plenum-CMP construction with a Flamarrest® PVC-LS jacket for indoor plenum environments. The cable is listed for Ethernet 10BASE-T, Ethernet 100BASE-TX, and Ethernet 1000BASE-T, and supports PoE, PoE+, and PoE++ power delivery. It is compliant with IEEE 802.3bt Type 1, Type 2, Type 3, and Type 4.
Belden 2413 010U Key Features
- Category 6+ enhanced premise horizontal cable (350MHz) for balanced high-frequency transmission.
- 4 pairs of 23 AWG solid bare copper conductors in a U/UTP design.
- Plenum-CMP rated for plenum indoor installations.
- Flamarrest® PVC-LS jacket with black jacket color.
- Supports PoE, PoE+, and PoE++ power delivery and complies with IEEE 802.3bt Type 1, Type 2, Type 3, and Type 4.
- Listed for Ethernet 10BASE-T, Ethernet 100BASE-TX, and Ethernet 1000BASE-T.
Belden 2413 010U Applications
- Designed for premise horizontal cable runs in indoor plenum spaces where Plenum-CMP fire performance is required.
- Supports Ethernet 1000BASE-T network links in structured cabling installations.
- Provides Ethernet 100BASE-TX connections in premise networking environments.
- Works in Ethernet 10BASE-T installations where this Ethernet standard is specified.
- Meets PoE, PoE+, and PoE++ powering needs for IEEE 802.3bt Type 1, Type 2, Type 3, and Type 4 deployments.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Data category | Category 6 |
| Insulation Material | PO+FEP - Polyolefin + Fluorinated Ethylene Propylene |
| Pair color code | White/Blue Stripe & Blue, White/Orange Stripe & Orange, White/Green Stripe & Green, White/Brown Stripe & Brown |
| Separator | Dielectric Tape (Patented) |
| Outer jacket material | PVC - Polyvinyl Chloride |
| Ripcord | Yes |
| Overall cable diameter (nominal) | 0.224 in (5.69 mm) |
| Bend radius (stationary min.) | 1.0 in (25 mm) |
| Bend radius (installation min.) | 2.25 in (57.2 mm) |
| Max Pull Tension | 25 lbs (11 kg) |
| Bulk cable weight | 26 lbs/1000ft |
| Max. Conductor DCR | 78 Ohm/km (24 Ohm/1000ft) |
| Max. capacitance unbalance | 330 pF/100m |
| Delay (100 MHz) max. | 537.6 ns/100m |
| Delay skew (100 MHz) max. | 35 ns/100m |
| Nom. velocity of prop. | 72% |
| UL Voltage Rating | 300 V (CMP), 300 V (CL3P) |
| UL temperature | 90°C |
| Operating temperature | -20°C To +75°C |
| Installation temperature | 0°C To +50°C |
| Storage temperature | -20°C To +75°C |
| Flammability / reaction to fire | NFPA 262, UL 910 (Plenum), FT6, IEC 60332-1-2 |
| NEC / UL compliance | Article 800, CMP, CMP-LP (0.5A), CL3P-LP (0.5A) |
| CEC / C(UL) compliance | CMP |
| ICEA compliance | S-116-732 |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 6 |
| ISO/IEC compliance | ISO/IEC 11801-1, IEC 61156-5 |
| NEMA Compliance | ANSI/NEMA WC-66 |
| CPR compliance | CPR Euroclass: Eca; CPR UKCA Class: Eca |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| UK regulation compliance | UKCA Mark |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Sustainability | Product Lens™, Environmental Product Declaration (EPD) Available |
| Third party performance verification | Category 6 |
| Non-Plenum number | 2412 |
| Patent information | This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents. |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
