Belden 2413FS 009, CAT6 4P UTP 23 AWG CMP FEP LSPVC 300V, White Jacket
SKU:Belden 2413FS 009
● In stock
× 1,000 ft = Total: 1,000 ft
Description
Belden 2413FS 009 is a Category 6+ enhanced premise horizontal cable (350MHz) designed for data networking in noisy environments. It features a 4 pair, 23 AWG solid bare copper F/UTP construction with a 100% foil shield and a patented X-Spline® center member. This cable is plenum-CMP rated with a Flamarrest® PVC-LS jacket, includes FEP insulation, and carries a UL voltage rating of 300 V (CMP). The jacket is white, and the cable is specified for plenum, indoor pathways.
Belden 2413FS 009 Key Features
- Category 6+ enhanced premise horizontal cable (350MHz) specified for data networking installations.
- F/UTP foil-shielded design with 100% foil coverage for performance in noisy environments.
- 4 pair, 23 AWG solid bare copper conductors.
- Plenum-CMP fire rating with a Flamarrest® PVC-LS jacket in white.
- Patented X-Spline® center member with PVC - Polyvinyl Chloride separator material.
Belden 2413FS 009 Applications
- Designed for premise horizontal cable runs where structured cabling is installed across indoor building spaces.
- Supports Ethernet 1000BASE-T links in network infrastructure.
- Enables Ethernet 100BASE-TX connections in compatible systems.
- Provides Ethernet 10BASE-T connectivity where required.
- Used in surveillance installations where network cabling is needed.
- Supports PoE++, PoE+, PoE deployments for delivering power over Ethernet.
- Intended for noisy environments where foil shielding is specified.
Patent Notice
- This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Type | Data |
| Data category | Category 6 |
| Insulation Material | FEP - Fluorinated Ethylene Propylene |
| Insulation color code | White & Blue, White & Orange, White & Green, White & Brown |
| Shield Type | Tape |
| Shield Material | Polyester + Bi-Laminate (Alum+Poly) |
| Drain Wire | 26 AWG (7x34) TC |
| Ripcord | No |
| Non-Plenum number | 2412FS |
| Overall cable diameter (nominal) | 0.255 in (6.48 mm) |
| Bulk cable weight | 37 lbs/1000ft (55 kg/km) |
| UL Voltage Rating | 300 V (CMP) |
| Max. Conductor DCR | 93.8 Ohm/km (28.6 Ohm/1000ft) |
| Max. capacitance unbalance | 330 pF/100m |
| Delay (100 MHz) | 537.6 ns/100m |
| Max. delay skew (100 MHz) | 45 ns/100m |
| Nom. velocity of prop. (100 MHz) | 72% |
| UL temperature | 105°C |
| Operating temperature | -20°C To +75°C |
| Storage temperature | -20°C To +75°C |
| Bend radius (stationary min.) | 1.0 in (25 mm) |
| Bend radius (installation min.) | 2.55 in (64.8 mm) |
| Max Pull Tension | 25 lbs (11 kg) |
| Environmental suitability | Plenum, Indoor |
| Flammability / reaction to fire | NFPA 262, UL 910 (Plenum), FT6, IEC 60332-1-2 |
| CPR Euroclass | Eca |
| NEC / UL | Article 800, CMP, CL3P-LP (0.5A), CMP-LP (0.5A) |
| CEC / C(UL) | CMP |
| ICEA | S-116-732 |
| IEEE | IEEE 802.3bt Type 1, Type 2, Type 3, Type 4 |
| NEMA | ANSI/NEMA WC-66 |
| TIA/EIA | ANSI/TIA-568.2-D Category 6 |
| ISO/IEC | ISO/IEC 11801-1, IEC 61156-5 |
| Third party performance verification | Category 6 |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Priced Per | FT |
