Belden 30806 010 6 AWG TC Wire Silicone Black Fiber Glass Jacket
Description
Belden 30806 010 is a hook-up, rubber wire with a 6 AWG stranded (84x25) tinned copper conductor. It features silicone rubber insulation and an overall lacquered glass braid covering jacket. It is rated 600V and 200°C and is UL AWM Style 3125.
Applications
- Use this hook-up, rubber wire in installations that require silicone rubber insulation and a glass braid covering jacket.
- Choose it for wiring tasks that call for a 600V rating and operation up to 200°C.
- Specify it for builds or equipment wiring where UL AWM Style 3125 is required.
Specifications
| Attribute | Value |
|---|---|
| # of Conductors | 1 Conductor |
| Conductor Gauge Size | 6 AWG |
| Conductor Type | Stranded Tinned Copper |
| Insulation Material | Silicone Rubber |
| Jacket Material | Fiber Glass |
| Shield (Y N) | no |
| Temperature | 200°C |
| Voltage | 600V |
| Item Type | Belden Lead Wire & Hook-Up Wire |
| Weight /LBS per 1000FT | 142 |
| Other Part Numbers | 30806 010, 30806 010100, 30806 010250, 30806 010500, 30806 0101000, UPC 612825140597, UPC 612825140610, UPC 612825140603 |
| Priced Per | FT |
