Belden 3632 009A, Enhanced Category 6 Cable 4 Pair U/UTP CMR White
Description
Belden 3632 009A is a Category 6 premium premise horizontal data cable rated to 400MHz. It features 4 bonded-pairs of 23 AWG solid bare copper conductors in a U/UTP design and includes a patented X-Spline® center member to help maintain pair geometry. This riser-rated Riser-CMR cable uses a PVC jacket and is intended for riser, indoor installations.
Belden 3632 009A Key Features
- Category 6 data cable rated to 400MHz for premise horizontal installations.
- 4 bonded-pairs of 23 AWG solid bare copper conductors in a U/UTP (Unshielded Twisted Pair) design.
- Patented X-Spline® center member separator to help maintain pair geometry.
- PVC jacket with Riser-CMR fire rating for riser, indoor pathways.
Belden 3632 009A Applications
- Designed for premise horizontal cable runs where structured cabling is installed across a floor or within a building.
- Supports Ethernet 10BASE-T connections in compatible network installations.
- Enables Ethernet 100BASE-TX links for network connectivity.
- Works with Ethernet 1000BASE-T for Gigabit Ethernet networks.
- Suitable for PoE, PoE+, and PoE++ deployments where power is delivered over Ethernet cabling.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Cable type | Data |
| Number of pairs | 4 |
| Bonded-pair | Yes |
| Conductor stranding | Solid |
| Conductor Material | BC - Bare Copper |
| Insulation Material | PO - Polyolefin |
| Insulation color code | White/Blue Stripe & Blue, White/Orange Stripe & Orange, White/Green Stripe & Green, White/Brown Stripe & Brown |
| Separator material | PVC - Polyvinyl Chloride |
| Ripcord | Yes |
| Jacket Color | White |
| Plenum number | 3633 |
| Overall cable diameter (nominal) | 0.234 in (5.94 mm) |
| Bulk cable weight | 26 lbs/1000ft |
| Max. Conductor DCR | 77 Ohm/km (23 Ohm/1000ft) |
| Max. capacitance unbalance | 90 pF/100m |
| Delay (100 MHz) max. | 537.6 ns/100m |
| Delay skew (100 MHz) max. | 35 ns/100m |
| Nom. velocity of prop. (100 MHz) | 70% |
| Typical delay skew (100 MHz) | 30 ns/100m |
| UL Voltage Rating | 300 V (CMR), 300 V (CL3R) |
| UL temperature | 90°C |
| Operating temperature | -20°C To +75°C |
| Installation temperature | 0°C To +50°C |
| Storage temperature | -20°C To +75°C |
| Bend radius (stationary min.) | 0.5 in (13 mm) |
| Bend radius (installation min.) | 2.5 in (64 mm) |
| Max Pull Tension | 40 lbs (18 kg) |
| Environmental suitability | Riser, Indoor |
| Flammability / reaction to fire | UL 1666 Riser, FT4, IEC 60332-1-2 |
| CPR compliance | CPR Euroclass: Eca; CPR UKCA Class: Eca |
| NEC / UL compliance | Article 800, CMR, CMR-LP (0.5A), CL3R-LP (0.5A) |
| CEC / C(UL) compliance | CMR |
| ICEA compliance | S-116-732 |
| IEEE compliance | IEEE 802.3bt Type 1, Type 2, Type 3, Type 4 |
| NEMA Compliance | ANSI/NEMA WC-66 |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 6 |
| Third party performance verification | Category 6 |
| ISO/IEC compliance | ISO/IEC 11801-1, IEC 61156-5 |
| CENELEC compliance | Segregation class according EN50174-2 = a |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| UK regulation compliance | UKCA Mark |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Sustainability | Product Lens™, Environmental Product Declaration (EPD) Available |
| Patent | This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents . |
| Priced Per | FT |
