Belden 3633 D15U, Enhanced Cat6 4 Pair UTP CMP Blue Cable
Description
Belden 3633 D15U is a Category 6+ premium premise horizontal cable (400MHz) for high-performance Ethernet networks in plenum indoor spaces. It uses 4 bonded-pairs of 23 AWG solid bare copper conductors in a U/UTP construction, with FEP insulation and a patented X-Spline® center member. The cable is finished with a Flamarrest® PVC-LS jacket in blue and supports PoE, PoE+, and PoE++.
Belden 3633 D15U Key Features
- Category 6+ premium premise horizontal cable (400MHz) for structured cabling runs.
- U/UTP construction with 4 bonded-pairs to help maintain pair geometry during installation.
- 23 AWG solid bare copper conductors for Ethernet network cabling.
- FEP - Fluorinated Ethylene Propylene insulation with the specified pair color code.
- Plenum-CMP jacketed design with a Flamarrest® PVC-LS jacket in blue.
- Patented X-Spline® center member and ripcord for cable management during pulls.
- Supports PoE, PoE+, and PoE++.
- Meets NFPA 262 and UL 910 (Plenum).
Belden 3633 D15U Applications
- Intended for premise horizontal cable installations in plenum indoor spaces.
- Enables Ethernet 10BASE-T connectivity in network cabling layouts.
- Supports Ethernet 100BASE-TX links for Fast Ethernet network runs.
- Handles Ethernet 1000BASE-T connections for Gigabit Ethernet deployments.
- Allows powering connected devices over the same cabling with PoE, PoE+, and PoE++.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Data category | Category 6 |
| Type | Data |
| Third party performance verification | Category 6 |
| Non-Plenum number | 3632 |
| Insulation color code | White/Blue Stripe & Blue, White/Orange Stripe & Orange, White/Green Stripe & Green, White/Brown Stripe & Brown |
| Jacket Material | PVC - Polyvinyl Chloride |
| Jacket trade name | Flamarrest® |
| Nom. diameter | 0.230 in (5.84 mm) |
| Overall cable diameter (nominal) | 0.230 in (5.84 mm) |
| Bulk cable weight | 31 lbs/1000ft |
| Max. Conductor DCR | 77 Ohm/km (23 Ohm/1000ft) |
| Max. capacitance unbalance | 90 pF/100m |
| UL Voltage Rating | 300 V (CMP), 300 V (CL3P) |
| Max. Delay (100 MHz) | 537.6 ns/100m |
| Max. delay skew (100 MHz) | 35 ns/100m |
| Nom. velocity of prop. (100 MHz) | 72% |
| Typical delay skew (100 MHz) | 30 ns/100m |
| Max Pull Tension | 40 lbs (18 kg) |
| Bend radius (stationary min.) | 0.5 in (13 mm) |
| Bend radius (installation min.) | 2.5 in (64 mm) |
| UL temperature | 105°C |
| Operating | -20°C To +75°C |
| Installation | 0°C To +50°C |
| Storage | -20°C To +75°C |
| Environmental suitability | Plenum, Indoor |
| Flammability / reaction to fire | NFPA 262, UL 910 (Plenum), FT6, IEC 60332-1-2 |
| NEC / UL compliance | Article 800, CMP, CMP-LP (0.6A), CL3P-LP (0.6A) |
| CEC / C(UL) compliance | CMP |
| ICEA compliance | S-116-732 |
| IEEE compliance | IEEE 802.3bt Type 1, Type 2, Type 3, Type 4 |
| NEMA Compliance | ANSI/NEMA WC-66 |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 6 |
| ISO/IEC compliance | ISO/IEC 11801-1, IEC 61156-5 |
| CENELEC compliance | Segregation class according EN50174-2 = a |
| CPR compliance | CPR Euroclass: Eca; CPR UKCA Class: Eca |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| UK regulation compliance | UKCA Mark |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Sustainability | Product Lens™, Environmental Product Declaration (EPD) Available |
| Patent notice | This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents . |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
