Belden 5302U1 010, Multi Conductor Water Blocked 4C 18 AWG PVC Black

Belden 5302U1 010 is a security & sound cable with 4-18 AWG stranded TC - Tinned Copper conductors, PVC - Polyvinyl Chloride insulation, and a PVC - Polyvinyl Chloride jacket. It includes waterblock tape for wet locations and below-grade duct installations. This cable is Rated-CMG-FPL-PLTC and carries a 300 V (CMG, FPL, PLTC-ER) rating with a 90°C UL temperature rating.

Key Features

• 4 conductors of 18 AWG stranded TC - Tinned Copper for security and sound wiring.
• PVC - Polyvinyl Chloride insulation with a PVC - Polyvinyl Chloride jacket.
• Waterblock tape for wet locations and below-grade duct installations.
• Ratings: Rated-CMG-FPL-PLTC.
• UL voltage rating: 300 V (CMG, FPL, PLTC-ER).
• UL temperature: 90°C.

Applications

• Use for security system wiring where a multi-conductor security & sound cable is required.
• Install in intercom/PA systems that need multiple conductors in a single run.
• Connect audio/speaker circuits in systems using power-limited wiring methods.
• Apply for power-limited controls covered under Article 725.
• Specify for wet location installations where waterblock tape is required.
• Run in below-grade duct installations where waterblocking is needed for the environment.
