Belden 5409UE 008, Multi Conductor 12C 20 AWG PP FRPVC Gray

Belden 5409UE 008 is a security & sound riser (CMR) cable with 12 stranded 20 AWG BC - Bare Copper conductors and a PVC - Polyvinyl Chloride jacket. PP - Polypropylene insulation and a defined color code support fast conductor identification in multi-channel installations. The cable is rated 300 V and supports a max current of 2.6 Amps per Conductor at 25ºC, with UL1666 Riser and FT4 fire ratings. A ripcord and sequential footage marking every two feet help streamline pulling and cut-length accuracy.

Key Features

• 12 stranded 20 AWG conductors support multi-channel security & sound wiring.
• BC - Bare Copper conductors with 7x28 stranding.
• PP - Polypropylene insulated conductors with color coding for quick identification.
• PVC - Polyvinyl Chloride jacket with a ripcord for easier stripping.
• UL voltage rating: 300 V; max. current: 2.6 Amps per Conductor at 25ºC.
• Fire rating: UL1666 Riser, FT4; NEC / UL compliance: Article 800, CMR; CEC / C(UL) compliance: CMG.
• Sequential footage marking every two feet supports efficient pulls and accurate cut lengths.
• Shield: No.

Applications

• Use in security system installations where multiple conductors are needed for organized field wiring.
• Support intercom/PA systems that benefit from clearly identified conductors during termination.
• Run audio/speaker lines requiring consistent identification across multi-channel connections.
• Specify for power-limited controls wiring where a 300 V rated cable is required.
