Belden 6100UE 010U, FLRST 2C 14 AWG Black Audio Cable
SKU:Belden 6100UE 010U
● In stock
Description
Belden 6100UE 010U is a plenum-rated security and commercial audio cable designed for clean, reliable signal delivery in intercom/PA systems and sound/audio systems. It features 2 x 14 AWG stranded bare copper conductors with PVC - Polyvinyl Chloride insulation and a PVC - Polyvinyl Chloride outer jacket. Electrical performance includes 2.54 Ohm/1000ft DCR, 36 pF/ft (120 pF/m) capacitance, and 0.145 μH/ft (0.476 μH/m) inductance, with a UL voltage rating of 300 V. It is suited for Indoor - Plenum installations and meets NFPA 262 and Article 725, CL2P requirements.
Key Features
- Plenum-rated design for Indoor - Plenum and Indoor environments.
- 2 x 14 AWG stranded bare copper conductors (19x26) for security and commercial audio wiring.
- PVC - Polyvinyl Chloride insulation and a PVC - Polyvinyl Chloride outer jacket.
- Ripcord included for easier stripping.
- UL voltage rating: 300 V.
- Flammability / reaction to fire: NFPA 262, UL 910 (Plenum), IEC 60332-1-2.
- NEC / UL compliance: Article 725, CL2P.
Applications
- Use in intercom/PA systems where consistent signal delivery is needed in indoor plenum spaces.
- Install in sound/audio systems in indoor environments that require plenum-rated cable.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Number of Conductors | 2 |
| Conductor size | 14 AWG |
| Conductor Material | BC - Bare Copper |
| Color Code | Black, White |
| Construction | Conductors cabled |
| Insulation nominal thickness | 0.010 in (0.25 mm) |
| Insulation nominal diameter | 0.090 in (2.3 mm) |
| Jacket nominal thickness | 0.015 in (0.38 mm) |
| Overall cable diameter (nominal) | 0.210 in (5.33 mm) |
| Bulk cable weight | 35 lbs/1000ft |
| Nom. conductor DCR | 2.54 Ohm/1000ft |
| Nom. capacitance cond-to-cond | 36 pF/ft (120 pF/m) |
| Nom. inductance | 0.145 µH/ft (0.476 µH/m) |
| Max. current | 25 Amps per Conductor @ 25°C |
| UL temperature | 75°C |
| Operating temperature | 0°C to +75°C |
| Installation temperature | 0°C to +75 |
| Bend radius (stationary min.) | 2.1 in (53 mm) |
| Bend radius (installation min.) | 2.1 in (53 mm) |
| Max Pull Tension | 95 lbs (43 kg) |
| CPR Euroclass | Eca |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| UK regulation compliance | UKCA Mark |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Non-Plenum number | 5100UE |
| Footage marking | Sequential footage marking every two feet |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
