Belden 7919A 010, 24 4P STP CAT 5E PVC Black Jacket
SKU:Belden 7919A 010
● In stock
× 1,000 ft = Total: 1,000 ft
Description
Belden 7919A 010 is an Industrial Ethernet Category 5e data cable with 4 pairs of 24 AWG solid bare copper conductors, PO insulation, and an overall Beldfoil® shield. It features a black PVC outer jacket and is listed for indoor/outdoor use with sunlight resistance and oil resistance. The cable meets UL1666 Riser and MSHA CMR, and electrical performance is specified through 100 MHz with controlled impedance of 100 ± 15 Ohm.
Belden 7919A 010 Key Features
- Category 5e data cable for Industrial Ethernet applications.
- 4 pairs of 24 AWG solid bare copper conductors with PO - Polyolefin insulation.
- Overall Beldfoil® shield (tape) with 100% coverage.
- Black PVC - Polyvinyl Chloride outer jacket.
- Environmental suitability includes indoor/outdoor, sunlight resistance, oil resistance, and aerial.
- Flammability / reaction to fire: UL1666 Riser, FT4, IEEE 1202 Vertical Tray Flame Test, IEC 60332-1-2.
- MSHA rating: MSHA CMR.
- Electrical performance specified through 100 MHz with 100 ± 15 Ohm impedance.
Belden 7919A 010 Applications
- Mining environments can use it where industrial data communication cabling is required.
- Harsh environment locations can rely on it when a rugged Industrial Ethernet cable is needed.
- IIoT networks can use it for Category 5e data communication links.
- Factory or process automation systems can use it for Industrial Ethernet connectivity.
- IP cameras and devices can connect over data networks using it.
- It supports general data communication in industrial and networked environments.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Color Code | White/Blue Stripe & Blue, White/Orange Stripe & Orange, White/Green Stripe & Green, White/Brown Stripe & Brown |
| Shield Material | Polyester + Bi-Laminate (Alum+Poly) |
| Drainwire type | 24 AWG (7x32) TC |
| Overall cable diameter (nominal) | 0.265 in (6.73 mm) |
| Bulk cable weight | 30 lbs/1000ft |
| Max. Conductor DCR | 93.8 Ohm/km (28.6 Ohm/1000ft) |
| Max. capacitance unbalance | 330 pF/ft |
| Max. delay | 538 ns/100m |
| Max. delay skew | 45 ns/100m |
| Nom. velocity of prop. | 70% |
| UL Voltage Rating | 300 V (CMR), 300 V (CMX-Outdoor) |
| High frequency performance (selected) | 1 MHz: Max. insertion loss 2.0 dB/100m; Min. NEXT 65.3; Min. PSNEXT 62.3; Min. RL 20; Min. SRL 23; 10 MHz: Max. insertion loss 6.5 dB/100m; Min. NEXT 50.3; Min. PSNEXT 47.3; Min. RL 25; Min. SRL 25; 100 MHz: Max. insertion loss 22.0 dB/100m; Min. NEXT 35.3; Min. PSNEXT 32.3; Min. RL 20.1; Min. SRL 20.1 |
| UL temperature | 60°C |
| Operating temperature | -40°C To +75°C |
| Installation temperature | -25°C To +75°C |
| Stationary min. bend radius | 1 in (25 mm) |
| Max Pull Tension | 25 lbs (11 kg) |
| CPR compliance | CPR Euroclass: Eca |
| NEC / UL compliance | Article 800, CMR, CMX-Outdoor |
| CEC / C(UL) compliance | CMX-Outdoor |
| NEMA Compliance | NEMA WC-63.1 |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 5e |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| UK regulation compliance | UKCA Mark |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Other standard compliance(s) | P-07-KA060004-MSHA |
| Item Type | Belden Networking cables |
| Other Part Numbers | 7919A 0101000, UPC 612825191216 |
| Priced Per | FT |
Documents
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
