Belden 7933A 010, Cat 5e 4 Pairs 24 AWG PVC Jacket, Black Jacket
SKU:Belden 7933A 010
● In stock
× 1,000 ft = Total: 1,000 ft
Description
Belden 7933A 010 is an Industrial Ethernet Category 5e cable designed for harsh environments, including IIoT, factory or process automation, and IP camera/data communication networks. It features 2 bonded-pair 24 AWG solid bare copper conductors, PO insulation, and an overall Beldfoil® shield for noise protection. The black PVC outer jacket is rated CMR and is sunlight- and oil-resistant for indoor/outdoor use. Electrical performance includes a UL voltage rating of 300 V (CMR) and controlled delay characteristics.
Belden 7933A 010 Key Features
- Industrial Ethernet Category 5e cable intended for harsh-environment networking.
- 2 bonded pairs with 24 AWG solid bare copper conductors.
- Overall Beldfoil® shield (tape) with 100% coverage for noise protection.
- Black PVC outer jacket with CMR fire rating for indoor/outdoor use.
- Sunlight resistance and oil resistance for installations where exposure to light and oils may occur.
- UL voltage rating: 300 V (CMR).
Belden 7933A 010 Applications
- Use it in harsh-environment installations where Industrial Ethernet connectivity is required.
- Support IIoT networks in industrial settings with this cable.
- Deploy it in factory or process automation networks to connect equipment and networked devices.
- Connect IP cameras and devices in networked video and device connectivity deployments.
- Rely on it for data communication networks where consistent electrical performance is needed.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Conductor | 24 AWG, Solid, BC - Bare Copper |
| Number of pairs | 2 |
| Bonded-pair | Yes |
| Insulation Material | PO - Polyolefin |
| Insulation color code | White/Orange Stripe & Orange, White/Green Stripe & Green |
| Shield Type | Tape |
| Shield Material | Bi-Laminate (Alum+Poly) |
| Drainwire type | 24 AWG (7x32) TC |
| Ripcord | No |
| Overall cable diameter (nominal) | 0.235 in (5.97 mm) |
| Bulk cable weight | 31 lbs/1000ft |
| Max. Conductor DCR | 93.8 Ohm/km (28.6 Ohm/1000ft) |
| Max. capacitance unbalance | 90 pF/100m |
| Max. delay | 552 ns/100m |
| Max. delay skew | 45 ns/100m |
| Nom. velocity of prop. | 70% |
| UL temperature | 60°C |
| Operating temperature | -40°C To +80°C |
| Installation temperature | -25°C To +60°C |
| Storage temperature | -40°C To +80°C |
| Stationary min. bend radius | 1.5 in (38 mm) |
| Max Pull Tension | 55 lbs (25 kg) |
| Flammability / reaction to fire | UL 1685 (FT4 Loading), FT4, IEEE 1202 Vertical Tray Flame Test, IEC 60332-1-2 |
| NEC / UL compliance | Article 800, CMR |
| CEC / C(UL) compliance | CMR |
| NEMA Compliance | NEMA WC-63.1 |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 5e |
| ISO/IEC compliance | ISO/IEC 11801-1, IEC 61156-5 |
| CPR compliance | CPR Euroclass: Eca |
| European directive compliance | EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16 |
| UK regulation compliance | UKCA Mark |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Patent information | This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents . |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
