Belden 7936A 010, Cat 5e 4 Pairs 24 AWG Solid PVC Jacket, Black Jacket
SKU:Belden 7936A 010
● In stock
× 1,000 ft = Total: 1,000 ft
Description
Belden 7936A 010 is an Industrial Ethernet Category 5e cable designed for data communication in noisy and harsh environments. It features 4 bonded-pairs of 24 AWG solid bare copper conductors, PO insulation, and an overall Beldfoil® shield for EMI protection. A LSZH outer jacket and compliance markings including CMG-ST1 and NFPA 130 support demanding installation requirements.
Belden 7936A 010 Key Features
- Category 5e data cable for Industrial Ethernet networks.
- 4 bonded-pairs with 24 AWG solid bare copper conductors to help maintain consistent pair geometry.
- PO (polyolefin) insulation with the specified insulation color code: White/Blue Stripe & Blue, White/Orange Stripe & Orange, White/Green Stripe & Green, White/Brown Stripe & Brown.
- Overall Beldfoil® shield with tape construction, Bi-Laminate (Alum+Poly) material, and 100% coverage.
- Drainwire type: 24 AWG (7x32) TC.
- LSZH outer jacket with a black jacket color.
- Sequential marking at two foot intervals.
- Compliance and verification include CM, CMG-ST1, NFPA 130, UL Verified to Category 5e, and ANSI/TIA-568.2-D Category 5e.
Belden 7936A 010 Applications
- Supports data communication in electrically noisy areas where EMI protection is needed.
- Often specified for shipboard installations where harsh conditions are expected.
- Serves transportation environments that call for durable Industrial Ethernet connectivity.
- Fits harsh-environment deployments in factory or process automation networks.
- Supports IIoT networks connecting industrial Ethernet devices.
- Works well for IP cameras and devices that rely on stable Ethernet data links.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Overall cable diameter (nominal) | 0.265 in (6.73 mm) |
| Bulk cable weight | 34 lbs/1000ft |
| Max. Conductor DCR | 93.8 Ohm/km (28.6 Ohm/1000ft) |
| Max. capacitance unbalance | 160 pF/100m |
| Max. delay | 538 ns/100m |
| Max. delay skew | 45 ns/100m |
| Nom. velocity of prop. | 70% |
| UL Voltage Rating | 300 V (CM), 300 V (CMG) |
| UL temperature | 75°C |
| Operating temperature | -10°C to +75°C |
| Installation temperature | +5°C to +75°C |
| Storage temperature | -10°C to +75°C |
| Stationary min. bend radius | 0.5 in (13 mm) |
| Max Pull Tension | 40 lbs (18 kg) |
| Environmental suitability | Indoor, Indoor, Outdoor, Sunlight Resistance |
| Flammability / reaction to fire | UL1685 UL Loading, IEC 60332-1-2 |
| CPR compliance | CPR Euroclass: Eca |
| ISO/IEC compliance | ISO/IEC 11801 Cat 5e |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| UK regulation compliance | UKCA Mark |
| Priced Per | FT |
