Belden 8520 003 14 AWG TC Orange PVC Insulation Wire
Description
Belden 8520 003 is low temp plastic hook-up wire with 14 AWG stranded (41x30) tinned copper conductors and orange PVC insulation. It is listed as Type MWP and includes military compliance: MIL-W-76C.
Applications
- Used for hook-up wiring where low temp plastic wire is needed for internal connections and general-purpose electrical interconnects.
- Meets wiring builds that call for MIL-W-76C compliance and Type MWP identification.
Specifications
| Attribute | Value |
|---|---|
| # of Conductors | 1 Conductor |
| Conductor Gauge Size | 14 AWG |
| Conductor Type | Stranded Tinned Copper |
| Insulation Material | PVC - Polyvinyl Chloride |
| Shield (Y N) | no |
| Item Type | Belden Lead Wire & Hook-Up Wire |
| Weight /LBS per 1000FT | 16 |
| Other Part Numbers | 8520 003, 8520 003100, 8520 003250, 8520 003500, 8520 0031000, UPC 612825210696, UPC 612825210702 |
| Priced Per | FT |
Documents
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
