Belden 8520 005, Hook Up Wire 1C 14 AWG Tinned Copper PVC, Green Jacket
Description
Belden 8520 005 is a low temp plastic lead wire for internal wiring in electrical and electronic equipment. It features a 14AWG (41x30) TC - Tinned Copper conductor with medium wall PVC - Polyvinyl Chloride insulation, rated TYPE MW MIL-W-76C-PVC 1000V 80C. This wire is rated 1000 V RMS and 80 Degrees Centigrade (176 F). The extruded PVC insulation is flame and ozone resistant and is inert to most chemicals, oils, and solvents.
Belden 8520 005 Applications
- Supports inter-connection circuits where dependable internal wiring is required within electrical and electronic equipment.
- Used for internal wiring of computer and electronic equipments to connect components and assemblies inside the device.
- Meets (Type MW) MIL-W-76C-Low Temp applications where this specification is required.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Conductor size | 14 |
| Stranding | 41x30 |
| Conductor Material | TC - Tinned Copper |
| Shielding | Not Shielded |
| Insulation Material | PVC - Polyvinyl Chloride |
| Insulation thickness (nom.) | 0.019 in (0.48 mm) |
| Insulation diameter (nom.) | 0.111 in (2.82 mm) |
| Insulation Color | Green |
| Jacket Color | Green |
| Voltage Rating | 1000 V RMS |
| Temperature rating | 80 Degrees Centigrade (176 F) |
| Type designation | TYPE MW MIL-W-76C-PVC 1000V 80C |
| Overall cable diameter (nom.) | 0.111 in (2.82 mm) |
| Bulk cable weight | 16 lbs/1000ft (24 kg/km) |
| Military compliance | MIL-W-76C Type MWP |
| Mil spec | MIL-W-76 |
| Product type | MW-76 |
| RoHS Compliant | Yes |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| Sustainability | CA Prop 65 |
| Item Type | Belden Lead Wire & Hook-Up Wire |
| Other Part Numbers | 8520 005, 8520 005100, 8520 005250, 8520 005500, 8520 0051000, UPC 612825210719, UPC 612825210726 |
| Priced Per | FT |
