Belden 8523 005, Hook Up Wire 1C 20 AWG Tinned Copper PVC

Belden 8523 005 is a low temp plastic lead wire for inter-connection circuits and the internal wiring of computer and electronic equipment. It is built with 1 x 20 AWG (10x30) TC - Tinned Copper and PVC - Polyvinyl Chloride insulation in Green. This wire is rated 1000 V RMS and 80°C, and supports 12.0 A for a single conductor in free air @ 30ºC. It is specified for Type MW MIL-W-76C-Low Temp applications and uses extruded PVC insulation that is flame and ozone resistant and inert to most chemicals, oils, and solvents.

Belden 8523 005 Key Features

• 1 x 20 AWG (10x30) TC - Tinned Copper conductor for low temp plastic lead wire builds.
• PVC - Polyvinyl Chloride insulation in Green.
• Rated 1000 V RMS and 80°C.
• Max. current for a single conductor in free air @ 30ºC: 12.0 A.
• Extruded PVC insulation is flame and ozone resistant and inert to most chemicals, oils, and solvents.
• Military compliance: MIL-W-76C Type MWP; product type: MW-76.
• European directive compliance: EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE); RoHS compliant: Yes.

Belden 8523 005 Applications

• Use it for inter-connection circuits where a low temp plastic lead wire is specified.
• Choose it for the internal wiring of computer and electronic equipment.
• Meet Type MW MIL-W-76C-Low Temp application requirements.

Belden™ and all associated trademarks are the property of their respective owners.
