Belden 8523 009, Hook Up Wire 1C 20 AWG Tinned Copper PVC

Belden 8523 009 is a low temp plastic lead wire for inter-connection circuits and internal wiring of computer and electronic equipments, including (Type MW) MIL-W-76C-Low Temp applications. It is a 1-conductor 20 AWG (10x30) TC - Tinned Copper wire with medium wall PVC - Polyvinyl Chloride insulation in White. This wire is rated 1000 V RMS and 80°C, with max. current for a single conductor in free air @ 30ºC of 12.0 A. The extruded PVC insulation is flame and ozone resistant and is inert to most chemicals, oils, and solvents, with environmental suitability listed as Outdoor.

Belden 8523 009 Key Features

• 1-conductor 20 AWG (10x30) TC - Tinned Copper construction for inter-connection circuits and internal wiring.
• Medium wall PVC - Polyvinyl Chloride insulation in White with a nominal thickness of 0.017 in (0.43 mm).
• Voltage rating: 1000 V RMS.
• UL temperature: 80°C; operating: -40°C to +80°C.
• Max. current: single conductor in free air @ 30ºC: 12.0 A.
• Flame and ozone resistant insulation that is inert to most chemicals, oils, and solvents.
• Shielded: Not Shielded.
• Environmental suitability: Outdoor.

Applications

• Supports inter-connection circuits where a low temp plastic lead wire is required.
• Used for internal wiring of computer and electronic equipments.
• Meets (Type MW) MIL-W-76C-Low Temp applications.
