Belden 8677 060, Multi Conductor Cable 2C 16 AWG PVC, Chrome Jacket
SKU:Belden 8677 060
● In stock
Description
Belden 8677 060 is a multi conductor cable with 2 stranded 16 AWG bare copper conductors, PVC insulation, and a chrome PVC jacket. It features parallel conductor construction and a 300 V rating for low voltage analog signals (4-20ma, 0-10v, ...), low voltage control (24v, …), and line level audio. This cable supports 6.5 Amps per Conductor at 25ºC and has an operating temperature range of -20°C To +75°C.
Belden 8677 060 Applications
- Supports low voltage analog signals (4-20ma, 0-10v, ...) where consistent signal transmission is needed.
- Use it for low voltage control (24v, …) wiring in control and automation circuits.
- It is suitable for line level audio connections where a clean, organized cable run is desired.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Number of Conductors | 2 |
| Conductor size | 16 AWG (American Wire Gauge) |
| Conductor stranding | 19x28 |
| Conductor Material | BC - Bare Copper |
| Conductor Type | Stranded Conductor |
| Insulation Material | PVC - Polyvinyl Chloride |
| Insulation nominal thickness | 0.024 in (0.61 mm) |
| Insulation nominal diameter | 0.20 in (5.1 mm) |
| Insulation color code | Brown, Red |
| Outer jacket material | PVC - Polyvinyl Chloride |
| Outer jacket nominal thickness | 0.022 in (0.56 mm) |
| Outer jacket nominal diameter | 0.149 x 0.254 in |
| Jacket Color | Chrome |
| Shield | No |
| Voltage Rating | 300 V |
| Max. current | 6.5 Amps per Conductor at 25ºC |
| UL temperature | 75°C |
| Operating temperature | -20°C To +75°C |
| Bend radius (stationary min.) | 0.38 in (9.7 mm) |
| Bend radius (installation min.) | 0.38 in |
| Max Pull Tension | 64.8 lbs (29.4 kg) |
| Bulk cable weight | 33 lbs/1000ft |
| European directive compliance | EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Item Type | Belden Multi Conductor Cable |
| Other Part Numbers | 8677 060, 8677 060100, 8677 060250, 8677 060500, 8677 0601000, UPC 612825214038 |
| Priced Per | FT |
Documents
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
