Belden 8917 002, Hook Up Wire 1C 16 AWG Tinned Copper RED PVC

Belden 8917 002 is a low temp plastic lead wire designed for hook-up and internal wiring in electronic and electrical equipment. It features a 1-conductor 16 AWG (26x30) TC - Tinned Copper conductor with PVC - Polyvinyl Chloride insulation and a 0.123 in (3.12 mm) nominal overall diameter. This wire is rated 600 V RMS and 105°C, with an operating temperature range of -30°C to +105°C.

Belden 8917 002 Key Features

• 1-conductor 16 AWG (26x30) TC - Tinned Copper construction for hook-up and internal wiring.
• PVC - Polyvinyl Chloride insulation with red insulation color.
• Rated 600 V RMS and 105°C for wiring in electronic and electrical equipment.
• Operating temperature: -30°C to +105°C.
• Flammability / reaction to fire: VW-1.

Belden 8917 002 Applications

• Supports inter-connection circuits where dependable internal wiring is needed in electronic and electrical equipment.
• Commonly used for internal wiring of computer and electronic equipments to connect components within enclosures.
• Works well for internal wiring of appliances where a single-conductor lead wire is required.
• Serves as machine tool wire for internal wiring tasks in equipment and control assemblies.
