Belden 8917 010, Hook Up Wire 1C 16 AWG Tinned Copper Black PVC
SKU:Belden 8917 010
$1.51/ FT
● In stock
Description
Belden 8917 010 is a low temp plastic lead wire designed for internal wiring in electronic and electrical equipment. It is a 1-conductor 16 AWG (26x30) wire with a TC - Tinned Copper conductor and PVC - Polyvinyl Chloride insulation. This wire is rated 600 V RMS and 105°C, and it meets AWM 1015 and AWM 1230 requirements. It is VW-1 flame rated for added safety.
Belden 8917 010 Key Features
- Supports dependable internal wiring in electronic and electrical equipment.
- Built with a 1-conductor 16 AWG (26x30) TC - Tinned Copper conductor for consistent electrical performance.
- Uses PVC - Polyvinyl Chloride insulation to support flexible routing in tight spaces.
- Rated 600 V RMS and 105°C for inter-connection circuits and internal wiring applications.
- Meets AWM 1015 and AWM 1230 requirements and is VW-1 flame rated.
Belden 8917 010 Applications
- Supports inter-connection circuits where dependable internal wiring is required.
- Designed for internal wiring of computer and electronic equipments.
- Suitable for internal wiring of appliances in electronic and electrical equipment.
- Serves as machine tool wire for internal wiring needs.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Number of Conductors | 1 |
| Conductor size | 16 AWG |
| Conductor stranding | 26x30 |
| Conductor Material | TC - Tinned Copper |
| Insulation Material | PVC - Polyvinyl Chloride |
| Shielding | Not Shielded |
| Insulation Color | Black |
| Nom. insulation thickness | 0.032 in (0.81 mm) |
| Nom. insulation diameter | 0.123 in (3.12 mm) |
| Overall cable diameter (nominal) | 0.123 in (3.12 mm) |
| Bulk cable weight | 14 lbs/1000ft |
| Nom. conductor DCR | 4.0 Ohm/1000ft |
| Max. current | Single Conductor in free air @ 30ºC: 26 A |
| Operating temperature | -30°C to +105°C |
| Bend radius (stationary min.) | 1.23 in (31.2 mm) |
| Bend radius (installation min.) | 1.23 in (31.2 mm) |
| Max Pull Tension | 37 lbs (17 kg) |
| Environmental suitability | Indoor, Outdoor |
| Sustainability | CA Prop 65 |
| NEC / UL compliance | Article 310, MTW |
| AWM compliance | AWM 1015, AWM 1230, CSA AWM I A/B |
| CEC / C(UL) compliance | TEW |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| RoHS Compliant | Yes |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
