Belden 8918 010, Hook Up Wire 1C 18 AWG Tinned Copper Black PVC
Description
Belden 8918 010 is a low temp plastic lead wire designed for dependable internal wiring in electronic and electrical equipment. It is a 1-conductor 18 AWG (16x30) TC - tinned copper wire with PVC - Polyvinyl Chloride insulation in black. This hook up wire is rated 105°C and 600 V RMS, and it meets AWM 1015, AWM 1230, CSA TYPE TEW, and VW-1 flammability requirements.
Belden 8918 010 Key Features
- 1-conductor 18 AWG (16x30) TC - tinned copper construction for internal wiring and inter-connection circuits.
- PVC - Polyvinyl Chloride insulation with black insulation color.
- Rated 105°C and 600 V RMS for wiring in electronic and electrical equipment.
- Meets AWM 1015, AWM 1230, CSA TYPE TEW, and VW-1 flammability.
- Not shielded design.
Belden 8918 010 Applications
- Supports inter-connection circuits where dependable internal wiring is required.
- Used for internal wiring of computer and electronic equipments in electronic and electrical equipment.
- Fits appliance internal wiring where a 105°C, 600 V RMS lead wire is specified.
- Works in machine tool wire installations for internal wiring and inter-connection circuits.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Product type | UL Styles 1000-1999 |
| UL style | UL Type AWM, Style 1015 |
| Nom. insulation thickness | 0.033 in (0.84 mm) |
| Nom. insulation diameter | 0.11 in (2.8 mm) |
| Overall cable diameter (nominal) | 0.11 in (2.8 mm) |
| Bulk cable weight | 10 lbs/1000ft |
| Nom. conductor DCR | 6.5 Ohm/1000ft |
| Max. current | Single Conductor in free air @ 30ºC: 20 A |
| Electrical rating note | Rated 2500V peak for electronic circuits, and internal wiring of electronic and electrical equipment |
| Operating temperature | -30°C to +105°C |
| Bend radius (stationary min.) | 1.1 in (28 mm) |
| Bend radius (installation min.) | 1.1 in (28 mm) |
| Max Pull Tension | 27 lbs (12 kg) |
| Environmental suitability | Indoor, Outdoor |
| AWM compliance | AWM 1015, AWM 1230, CSA AWM I A/B |
| CEC / C(UL) compliance | TEW |
| NEC / UL compliance | Article 310, MTW |
| Sustainability | CA Prop 65 |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| RoHS Compliant | Yes |
| Priced Per | FT |
