Belden 9463 003 1-Pr 20 AWG Str O/A Beldfoil Orange PVC Jacket
SKU:Belden 9463 003
$316.80
● In stock
Description
Belden 9463 003 is a Blue Hose® cable for Data Highway Plus with 1 pair 20 AWG stranded (7x28) tinned copper conductors. It features PE insulation in blue and clear, an overall Beldfoil® plus tinned copper braid (55%) shield, and an orange PVC outer jacket. CM.
Applications
- Use for Data Highway Plus installations where Blue Hose® cable is specified.
- Choose for runs that benefit from an overall shield construction for cable routing and system connectivity.
- Select for projects that require an orange PVC outer jacket for identification and cable management.
Specifications
| Attribute | Value |
|---|---|
| # of Conductors | 1 Pair |
| Conductor Gauge Size | 20 AWG |
| Conductor Type | Stranded |
| Insulation Material | PE - Polyethylene |
| Shield Type | Overall Beldfoil®+ 55% Tinned Copper Braid |
| Jacket Material | PVC - Polyvinyl Chloride |
| Conductor Material | TC - Tinned Copper |
| Shield (Y N) | Yes |
| Approvals | Article 725, Article 800, CM, CL2 |
| Item Type | Belden Multi-Pair Cable |
| Weight /LBS per 1000FT | 36 |
| Other Part Numbers | 9463 003100; 9463 003250; 9463 003500; 9463 0031000 |
| Priced Per | FT |
Documents
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
