Belden 9463 007 1-Pr 20 AWG Str O/A Beldfoil Violet PVC Jacket
SKU:Belden 9463 007
$316.80
● In stock
Description
Belden 9463 007 Blue Hose® for Data Highway Plus is a 1 pair 20 AWG stranded cable with a violet PVC outer jacket. It features blue & clear PE insulation and an overall Beldfoil® + tinned copper braid (55%) shield. The cable is marked CM.
Applications
- Use for Data Highway Plus wiring where a 1-pair, 20 AWG stranded construction is required.
- Choose this cable for installations that call for an overall Beldfoil® + tinned copper braid (55%) shield.
- Identify conductors in the field using blue & clear PE insulation.
Specifications
| Attribute | Value |
|---|---|
| Series | Blue Hose® |
| Type | for Data Highway Plus |
| Pairs | 1-Pr |
| Conductor size | 20 AWG |
| Stranding | Str (7x28) |
| Conductor Material | Tinned Copper |
| Insulation | PE |
| Insulation Colors | Blue & Clear |
| Overall shield | Beldfoil®+Tinned Copper Braid (55%) |
| Outer jacket | Violet PVC |
| Rating | CM |
| Item Type | Belden Multi-Pair Cable |
| Other Part Numbers | 9463 007100; 9463 007250; 9463 007500; 9463 0071000 |
| Priced Per | FT |
Documents
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
