Belden 9918 013, Hook Up Wire 1C 18 AWG Tinned Copper PVC
Description
Belden 9918 013 is a low temp plastic lead wire for internal wiring in electronic and electrical equipment. It features 1-conductor 18 AWG stranded (16x30) TC - Tinned Copper with PVC - Polyvinyl Chloride insulation. Electrical ratings include UL Voltage Rating: 300 V RMS, Max. current: Single Conductor in free air @ 30ºC: 20 A, and Nom. Conductor DCR: 7.15 Ohm/1000ft.
Belden 9918 013 Applications
- Supports inter-connection circuits that require dependable internal wiring within electronic and electrical equipment.
- Used for internal wiring of computer and electronic equipments to route connections within enclosures and assemblies.
- Works for internal wiring of appliances where internal component connections are required.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Number of Conductors | 1 |
| Conductor size | 18 AWG |
| Stranding | 16x30 |
| Conductor Material | TC - Tinned Copper |
| Insulation Material | PVC - Polyvinyl Chloride |
| Nom. insulation thickness | 0.017 in (0.43 mm) |
| Nom. insulation diameter | 0.079 in (2.0 mm) |
| Overall cable diameter (nominal) | 0.079 in (2.0 mm) |
| Bulk cable weight | 7 lbs/1000ft |
| UL Voltage Rating | 300 V RMS |
| Nom. conductor DCR | 7.15 Ohm/1000ft |
| Max. current | Single Conductor in free air @ 30ºC: 20 A |
| UL temperature | 105°C |
| Operating | -25°C To +105°C |
| Bend radius (stationary min.) | 0.79 in (20 mm) |
| Bend radius (installation min.) | 0.79 in (20 mm) |
| Max Pull Tension | 21 lbs (9.5 kg) |
| Environmental suitability | Indoor |
| Flammability / reaction to fire | VW-1 |
| AWM compliance | AWM 1007, AWM 1569 |
| CEC / C(UL) compliance | TRSR-64 |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Sustainability | CA Prop 65 |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
