Belden 1350SB 010, Multi Conductor AES EBU Cable 1 FS PR 24 AWG

Belden 1350SB 010 is a digital audio cable designed for AES/EBU and other low-capacitance signal applications. It features 1 pair of 24 conductors using TC - Tinned Copper with PE - Polyethylene (Foam) insulation and a Red & Black color code. For noise rejection and grounding, it uses a Tape shield made of Bi-Laminate (Alum+Poly) with 100% coverage, plus an overall Beldfoil® shield and drain. The LSZH - Low Smoke Zero Halogen (Flame Retardant) jacket and Rated-CMG-LS construction support use in demanding environments, including shipboard installations.

Key Features

• 1 pair construction with 24 conductors and 7x32 stranding for consistent signal cabling.
• Overall Beldfoil® tape shield with 100% coverage and a drain wire for noise rejection and grounding.
• LSZH - Low Smoke Zero Halogen (Flame Retardant) outer jacket.
• Rated-CMG-LS construction.
• Nom. characteristic impedance: 100 Ohm.
• UL voltage rating: 300 V RMS.
• Operating: -30°C to +75°C.

Applications

• Supports shipboard installations, including ABS-listed environments.
• Handles digital audio and analog audio signal runs, including AES/EBU systems.
• Meets low-capacitance signal applications where consistent performance and noise rejection matter.
• Fits instrumentation and control wiring where shielded signal integrity is needed.
• Integrates into EIA RS-232, EIA RS-422, and EIA RS-485 systems.

Belden™ and all associated trademarks are the property of their respective owners.
