Belden 1617R 010, RG11 14 Solid SSC FPE SHDPVC Jacket CATV 75 OHM
SKU:Belden 1617R 010
● In stock
Description
Belden 1617R 010 is a Series 11 RG Type 11 coaxial cable with a 14 AWG solid BCCS - Bare Copper Covered Steel conductor and a PVC - Polyvinyl Chloride jacket. It features gas-injected PE - Polyethylene (Foam) insulation and a Quad Shield (F/B+F/B) design for 75 Ohm broadband video/RF distribution. The cable is intended for Indoor - Riser installations and meets CATVR, CMR, and UL1666 Riser requirements.
Key Features
- Series 11 RG Type 11 coaxial construction with 1 coax and 1 conductor.
- 14 AWG solid BCCS - Bare Copper Covered Steel conductor.
- Gas-injected PE - Polyethylene (Foam) insulation.
- Quad Shield (F/B+F/B) shielding with Duofoil® tape layers and aluminum braid layers (60% and 40%).
- PVC - Polyvinyl Chloride jacket for Indoor - Riser use; plenum (Y/N): No.
- NEC/(UL) compliance: CATVR, CMR; UL flammability: UL1666 Riser; CEC/C(UL) compliance: CMG.
Applications
- Designed for CATV and other 75 Ohm broadband video/RF distribution runs.
- Suitable for indoor riser installations requiring CATVR, CMR, and UL1666 Riser performance.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Coax Type | RG 11 |
| RG type | 11 |
| Series type | 11 |
| Coax construction | Coaxial |
| Number of coax | 1 |
| Number of Conductors | 1 |
| Conductor nominal diameter | 0.064 in |
| Insulation nominal diameter | 0.28 in |
| Jacket nominal diameter | 0.407 in |
| Nominal characteristic impedance | 75 Ohm |
| Nominal characteristic tolerance | ± 3 Ohm |
| Nom. capacitance (Conductor to Shield) | 16.2 pF/ft |
| Nominal inductance | 0.097 μH/ft |
| Nominal delay | 1.2 ns/ft |
| Nominal velocity of propagation (VP) [%] | 83% |
| Return Loss Frequency [MHz] | 5 - 1000 MHz |
| Min. structural return loss (SRL) | 20 dB |
| Non-UL voltage rating | 300 V RMS |
| UL Voltage Rating | 300 V RMS |
| Attenuation @ 5 MHz | 0.38 dB/100ft |
| Attenuation (55 MHz) | 0.96 dB/100ft |
| Attenuation @ 211 MHz | 1.9 dB/100ft |
| Attenuation (270 MHz) | 2.13 dB/100ft |
| Attenuation @ 300 MHz | 2.25 dB/100ft |
| Attenuation @ 350 MHz | 2.42 dB/100ft |
| Attenuation @ 400 MHz | 2.6 dB/100ft |
| Attenuation 450 MHz | 2.75 dB/100ft |
| Attenuation @ 550 MHz | 3.04 dB/100ft |
| Attenuation (750 MHz) | 3.65 dB/100ft |
| Attenuation @ 870 MHz | 4.06 dB/100ft |
| Attenuation @ 1000 MHz | 4.35 dB/100ft |
| Nominal conductor DCR | 11 Ohm/1000ft |
| Nominal outer shield DCR | 3 Ohm/1000ft |
| Outer conductor DCR | 3 Ohm/1000ft |
| UL Temperature Rating | 80°C |
| Operating Temperature Range | -40°C To +80°C |
| Bulk cable weight | 59 lbs/1000ft |
| Maximum recommended pulling tension | 308 lbs |
| Minimum minor axis bend radius | 4.5 in |
| Suitability - indoor | Yes |
| EU Directive 2000/53/EC (ELV) | Yes |
| EU Directive 2003/96/EC (BFR) | Yes |
| EU Directive 2011/65/EU (RoHS 2) | Yes |
| EU Directive 2012/19/EU (WEEE) | Yes |
| EU Directive 2015/863/EU (RoHS 2 amendment) | Yes |
| EU directive compliance | EU Directive 2003/11/EC (BFR) |
| EU CE mark | No |
| MII Order #39 (China RoHS) | Yes |
| Footnote | C - CRATE REEL PUT-UP. |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
