Belden D6UP 010U, 24 4P UTP CMP Solid BC CAT6 FEP PVC BLACK
SKU:Belden D6UP 010U
● In stock
× 1,000 ft = Total: 1,000 ft
Description
Belden D6UP 010U is a Category 6 premise horizontal cable (250MHz) designed for plenum spaces. It is a U/UTP data cable with 4 pairs of solid bare copper conductors and PO+FEP insulation, finished with a Flamarrest® PVC-LS jacket in black. Key electrical and installation details include UL Voltage Rating: 300 V (CMP), UL temperature: 75°C, and a ripcord for easier jacket removal. It meets NFPA 262 and UL 910 (Plenum) and aligns with ANSI/TIA-568.2-D Category 6 and ISO/IEC 11801-1.
Belden D6UP 010U Key Features
- Category 6 premise horizontal cable (250MHz) for structured cabling installations.
- U/UTP shielding design for data networking applications.
- 4 pairs of solid bare copper conductors with Conductor Size: 23.
- PO+FEP - Polyolefin + Fluorinated Ethylene Propylene insulation with defined pair color code.
- Flamarrest® PVC-LS jacket in black with Ripcord: Yes for easier jacket removal.
- Plenum indoor suitability with Flammability / reaction to fire: NFPA 262, UL 910 (Plenum).
Belden D6UP 010U Applications
- Specified for premise horizontal cable installations.
- Supports Ethernet 1000BASE-T network connections.
- Supports Ethernet 100BASE-TX network connections.
- Supports Ethernet 10BASE-T network connections.
- Listed for surveillance connectivity.
- Intended for PoE++, PoE+, and PoE deployments.
Belden™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Type | Data |
| Data category | Category 6 |
| Number of pairs | 4 |
| Stranding | Solid |
| Conductor Material | BC - Bare Copper |
| Insulation color code | White/Blue Stripe & Blue, White/Orange Stripe & Orange, White/Green Stripe & Green, White/Brown Stripe & Brown |
| Jacket Material | PVC - Polyvinyl Chloride |
| Nom. diameter | 0.224 in (5.69 mm) |
| Overall cable diameter (nominal) | 0.224 in (5.69 mm) |
| Bulk cable weight | 25 lbs/1000ft |
| Max. Conductor DCR | 78 Ohm/km (24 Ohm/1000ft) |
| Max. capacitance unbalance | 330 pF/100m |
| Frequency | 100 MHz |
| Max. delay | 537.6 ns/100m |
| Max. delay skew | 35 ns/100m |
| Nom. velocity of prop. | 72% |
| UL Voltage Rating | 300 V (CMP) |
| Max Pull Tension | 25 lbs (11 kg) |
| Bend radius (stationary min.) | 1.0 in (25 mm) |
| Bend radius (installation min.) | 2.25 |
| Operating | -20°C To +75°C |
| Installation | 0°C To +50°C |
| Storage | -20°C To +75°C |
| Environmental suitability | Plenum Indoor, Indoor |
| NEC / UL compliance | CMP |
| CEC / C(UL) compliance | CMP |
| CPR compliance | CPR Euroclass: Eca |
| TIA/EIA compliance | ANSI/TIA-568.2-D Category 6 |
| ISO/IEC compliance | ISO/IEC 11801-1, IEC 61156-5 |
| IEEE compliance | IEEE 802.3bt Type 1, Type 2, Type 3, Type 4 |
| Third party performance verification | Category 6 |
| European directive compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2017-07-10 |
| APAC compliance | China RoHS II (GB/T 26572-2011) |
| Sustainability | Product Lens™, Environmental Product Declaration (EPD) Available |
| Non-Plenum number | D6UR |
| Patents | This product has one or more applicable patents. More information on patents can be found at https://www.belden.com/patents . |
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
