Berk-Tek (Leviton) 10032091, LANmark 1000 Category 6 Plenum UTP Cable White

Berk-Tek (Leviton) 10032091 LANmark-1000 Category 6 Plenum U/UTP Cable is a Cat 6 data cable with a white CMP plenum jacket and 23 AWG solid conductors. It is ETL verified to ANSI/TIA/EIA-568-B.2-1 Category 6 standard and characterized to 550 MHz. Supplied on a 1000 ft (305 m) reel, it is designed to improve crosstalk performance and support Gigabit Ethernet.

Technical Specs

Product family	Copper cable
Brand	LANMARK-1000
Category rating	Cat 6
Type	Data
Construction	U/UTP
Shielding	U/UTP - Unshielded twisted pair
Conductor size	23 AWG (American Wire Gauge)
Conductor type	Solid
Pair count	4 pair
Flame rating	CMP
Fire rating	Plenum
Color	White
Jacket color	White
Length	1000 ft (305 m)
Packaging	Reel
Verification	ETL verified to ANSI/TIA/EIA-568-B.2-1 Category 6 standard
Characterization	Characterized to 550 MHz, 300 MHz greater than the standard
Compliance	RoHS Compliant
Performance	Full power sum performance
Balance characteristics	Documented balance characteristics (LCL, LCTL) to improve overall performance and reduce cable emissions
Crosstalk improvement	Redesigned electrical characteristics improve crosstalk performance by four dB
PSACR	Power Sum Attenuation to Crosstalk ratio (PSACR) nearly 3 times better (at 250 MHz) for stronger signals and reduced noise susceptibility

Applications

• Designed for high-performance copper networking installations in plenum spaces.
• Gigabit Ethernet is supported, and documented balance characteristics (LCL, LCTL) help reduce transmission errors.
• Power sum characterization helps maximize performance with existing applications and supports additional bandwidth for future applications.

Berk-Tek® is a premium brand of Leviton® Manufacturing Co., Inc., known for high-quality networking and cable solutions. All trademarks are the property of their respective owners.
