Berk-Tek (Leviton) 11142628, 23 4P UTP CMP Solid BC CAT6A LM RED DIA

Berk-Tek (Leviton) 11142628 is a Cat 6A U/UTP copper data cable with 23 AWG solid conductors and a white jacket. It features a reduced diameter of 0.230" (5.84 mm) and is rated CMP / plenum with a listing temperature of 105 C (221 F). The cable provides 8 dB PSANEXT and PSAACRF margin to Cat 6A requirements and includes a limited power (LP) rating of 0.7 A. It ships in a 1000 ft (305 m) TEKPAK Box.

Technical Specs

Brand	Global RDT
Product family	Copper Cable
RoHS compliant	Yes
Category rating	Cat 6A
Construction	U/UTP
Shielding	U/UTP - Unshielded Twisted Pair
Conductor size	23 AWG (American Wire Gauge)
Conductor type	Solid
Conductor/pair count	4 pair
Type	Data
Internal parameters	compliant with Cat 6A standards
PSANEXT / PSAACRF margin	8 dB PSANEXT and PSAACRF margin to Cat 6A requirements
Reduced diameter	0.230" (5.84 mm)
Color	White
Jacket color	White
Flame rating	CMP
Fire rating	Plenum
Limited power (LP) rating	0.7 A
Listing temperature	105 C (221 F)
Length	1000 ft (305 m)
Packaging	TEKPAK Box

Applications

• Supports 802.11ac wireless installations where Cat 6A performance is required.
• Works well for HD video network runs in plenum spaces.
• Use it for IP security cabling in high-density plenum installations where flexibility and cable management matter.

Berk-Tek® is a premium brand of Leviton® Manufacturing Co., Inc., known for high-quality networking and cable solutions. All trademarks are the property of their respective owners.
