Chatsworth Products 11900-E24, CUBE-iT+ Wall Mount Cabinet 12U 24 H x 19W x24 D White

Chatsworth Products 11900-E24 CUBE-iT® Wall-Mount Cabinet is a Gen 3 swing-out wall-mount enclosure for securely storing and servicing ICT equipment in space-limited areas. It supports 12U of 19" EIA mounting with #12-24 tapped rails and includes a tempered glass door with a single CH751 lock. Finished in Glacier White, the cabinet measures 24"H x 24"W x 24"D (610 mm x 610 mm x 610 mm). It ships fully assembled, is UL® 2416 Listed, and has a 300 lb (136 kg) load rating.

Chatsworth Products 11900-E24 Key Features

• The Gen 3, three-part swing-out design provides access to both the front and rear of installed equipment for service.
• A tempered glass front door with a single lock and key (CH751) provides access to the entire cabinet.
• An internal latch mechanism secures the rear panel, and the slim-profile design does not impact cabling space.
• The hinge design allows the installer to remove the rear panel for easier wall installation.
• The rear panel includes 1” (25.4 mm) and 3" (76 mm) knockouts and can accept 3/4” (19 mm) and 2.5” (63.5 mm) conduit.
• The 3” (76 mm) knockouts include edge-protection grommets for cable entry.
• The rear panel features cable tie and attachment points for accessory rack-mount brackets.
• A cable pass-through knockout with an optional brush seal supports retrofit installations.
• A factory-prepped bonding feature provides convenience and reduces installation time.
• An optional low-decibel (31 dB), dual-fan kit provides quiet operation while cooling equipment.

Chatsworth Products 11900-E24 Applications

• It is designed to securely store and service ICT equipment in space-limited areas.
• Use it where access to both the front and rear of installed gear is needed for maintenance.
• It helps protect equipment in public areas or equipment rooms with a tempered glass door and a single CH751 lock.
• It fits retrofit installations where a cable pass-through knockout with an optional brush seal is preferred.

Shipping & Availability

• Ships fully assembled.
• Ship width: 29" (74 cm)
• Ship length/depth: 74" (1880 mm)
• Ship height: 31" (79 cm)
• Shipping weight: 101 LB (45.81 kg)
