Chatsworth Products 11996-736, CUBE-iT+ Wall Mount Cabinet 18U 36 x 24 x 30 Black

Chatsworth Products 11996-736 CUBE-iT® Wall-Mount Cabinet (Gen 3) is a wall-mount cabinet with a solid metal door, black finish, and a three-part swing-out design for front and rear service access. It includes one pair of adjustable depth 19" EIA threaded equipment mounting rails with #12-24 tapped rails, supports 19U, and is rated for 300 lb (136 kg). This cabinet is UL® 2416 Listed and ships fully assembled. The rear panel includes multiple knockouts and conduit acceptance options to simplify cable entry and retrofit installations.

Chatsworth Products 11996-736 Key Features

• CUBE-iT® Wall-Mount Cabinet with a Gen 3 wall-mount design.
• A three-part, swing-out access design supports front and rear service access.
• A single lock and key (CH751) on the front door provides access to the entire cabinet.
• An internal rear panel latch mechanism secures the rear panel, and the slim profile does not impact cabling space.
• The hinge design allows the installer to remove the rear panel for easier wall installation.
• Rear panel knockouts include 1” (25.4 mm) and 3" (76 mm), with edge-protection grommets on the 3” (76 mm) knockouts.
• Conduit acceptance supports 3/4” (19 mm) and 2.5” (63.5 mm).
• A front-to-rear airflow design supports equipment cooling.
• The rear panel includes cable tie and attachment points for accessory rack-mount brackets.
• A cable pass-through knockout supports retrofit installations with an optional brush seal.
• An optional low-decibel (31 dB), dual-fan kit provides quiet operation while cooling equipment.
• A factory-prepped bonding feature provides convenience and reduces installation time.

Chatsworth Products 11996-736 Technical Specs

General Product Information

Product family	CUBE-iT® Wall-Mount Cabinet
Generation	Gen 3
Type	Wall-mount

Dimensions & Capacity

Height	36" (910 mm) 19U
Width	24" (610 mm)
Depth	30" (760 mm)
Mounting width	19"
Rack units	19U
Load rating	300 lb (136 kg)

Construction & Finish

Material	Aluminum/steel mix
Color	Black
Door style	Solid metal door
Multi-compartment	No

Mounting Rails

Rail style	Tapped
Rails	One pair of adjustable depth 19" EIA threaded equipment mounting rails
Rail threading	#12-24 tapped rails

Environmental & Mechanical Ratings

Nema rating	No NEMA rating
Seismic rating	No

Compliance & Origin

Compliance	UL® 2416 Listed
Country of origin	US
BABA compliant	Yes

Chatsworth Products 11996-736 Applications

• Provides secure wall-mount storage for ICT equipment in public areas.
• Works well in equipment rooms with limited floor space where wall-mounted installation is preferred.
• Simplifies cable entry and retrofit installations using rear panel knockouts, conduit acceptance options, and a cable pass-through knockout with an optional brush seal.
• Allows servicing installed gear from both the front and rear through the three-part swing-out design.

Shipping & Availability

Ship width	29" (74 cm)
Ship length/depth	104" (2642 mm)
Ship height	37" (94 cm)
Shipping weight	142 LB (64.41 kg)
