Corning 072TUF-T4180D20 —Fiber Cable, Loose Tube, LSZH, Blue, OM3 (Multimode), 72 Fiber

Corning 072TUF-T4180D20 —Fiber Cable, Loose Tube, LSZH, Blue, OM3 (Multimode), 72 Fiber

This product is designed for both indoor and outdoor use, offering reliable performance for aerial, direct buried, duct, riser, and general-purpose installations. Featuring a dielectric central element and flame-retardant UV-resistant black jacket, it ensures durability in harsh environments while maintaining compliance with NEC® OFCR and CSA OFC FT-4 standards. Its water-swellable tape and six color-coded buffer tubes (each containing 12 fibers) enable easy identification and high-density network builds. Engineered to operate in extreme temperatures from -40 °C to 70 °C, it provides low attenuation rates of 3.0 dB/km at 850 nm and 1.0 dB/km at 1300 nm, ensuring optimal data transmission. Ideal for high-speed Ethernet applications, it supports up to 1000 m for Gigabit Ethernet and 300 m for 10 Gigabit Ethernet.

General Specifications
Product Number: 072TUF-T4180D20
Cable Type: Loose Tube
Environment: Indoor/Outdoor
Product Type: Dielectric
Fiber Category: 50 µm MM (OM3)
Flame Rating: Riser (OFNR)
Application: Aerial, Direct Buried, Duct, General purpose, Horizontal, Riser
Cable geometry: Round

Standards
RoHS: Free of hazardous substances according to RoHS 2011/65/EU
Approvals and Listings: National Electrical Code® (NEC®) OFCR, CSA OFC FT-4
Common Installations: Outdoor aerial and duct, indoor vertical riser and general purpose horizontal according to NEC Article 770
Design and Test Criteria: ANSI/ICEA S-104-696

Environmental Conditions
Temperature Range, Installation: -10 °C to 60 °C (14 °F to 140 °F)
Temperature Range, Operation: -40 °C to 70 °C (-40 °F to 158 °F)
Temperature Range, Storage: -40 °C to 70 °C (-40 °F to 158 °F)

Cable Design
Central Element: Dielectric
Fiber Count: 72
Number of Ripcords: 2
Outer Jacket Color: Black
Outer Jacket Material: Flame-Retardant, UV-Resistant
Buffer Tube Color: Blue, Orange, Green, Brown, Slate, White
Buffer Tube Diameter: 2.5 mm (0.1 in)
Number of Active Tubes: 6
Number of Tube Positions: 6
Tape: Water-swellable
Fiber Coloring: Blue, Orange, Green, Brown, Slate, White, Red, Black, Yellow, Violet, Rose, Aqua
Fibers per Tube: 12
Color Code Standards: Telcordia

Mechanical Specifications
Max. Tensile Strength, Long-Term: 810 N (182.1 lbf)
Max. Tensile Strength, Short-Term: 2700 N (606.98 lbf)
Min. Bend Radius Installation: 195 mm (7.68 in)
Min. Bend Radius Operation: 130 mm (5.12 in)
Nominal Outer Diameter: 13 mm (0.51 in)

Optical Characteristics
Fiber Code: T
Performance Option Code: 80
Fiber Category: OM3
Fiber Type: Multimode
Fiber Name: 50 µm MM (OM3)
Maximum Attenuation: 3.0 dB/km / 1.0 dB/km
Wavelengths: 850 nm / 1300 nm
Fiber Compliance: IEC 60793-2-10
Fiber Core Diameter: 50 µm
Serial 1 Gigabit Ethernet: 1000 m / 600 m
Serial 10 Gigabit Ethernet: 300 m / -
Minimum Effective Modal Bandwidth (EMB): 950 MHzkm / -
Min. Overfilled Launch (OFL) Bandwidth: 1500 MHzkm / - 500 MHz*km

Dimensions
Cable Weight: 146 kg/km (98.11 lb/1000 ft)
