LAPP Group 1600119, H07RN F 12 AWG 3C 750V Flexible Cordage
SKU:1600119
● In stock
ft
Minimum order: 100 ft · Increments of 100 ft
Description
Part Number: 1600119
LAPP 1600119 H07RN F flexible cordage is built for demanding power and control applications where durability matters. This 12 AWG 3-Conductor cord features Stranded Conductors and a tough neoprene Jacket designed to stand up to oil, chemicals, and abrasion. Rated 750V and Unshielded, it’s well-suited for high-stress use in dry and damp environments, including outdoor installations with UV exposure. It’s also a practical MRO replacement option for European machinery using H07RN-F style cordage.
Electrical & Construction:
- Manufacturer: LAPP
- Manufacturer part number: 1600119
- Voltage: 750V
- AWG/gauge: 12
- Number Of Conductors: 3
- Conductor Stranding: Stranded
- Shielding: Unshielded
Materials:
- Conductor Material: Tinned Or Coated Copper
- Insulation Material: EPR-Ethylene Propylene Rubber
- Jacket Material: Neoprene
- Jacket Material (additional listing): NEO Neoprone, Polychloroprene
Grounding:
- Earth/ground wires: Yes
- Number of ground wires: 1 Wire
Product Type & Compliance:
- Product type: OZOFLEX
- RoHS compliant: No
Performance & Typical Uses:
- Neoprene Jacket helps resist oil, chemicals, and abrasion
- Designed for high-stress applications in dry and damp environments
- UV resistant for Outdoor Use
- Commonly used as an MRO replacement for European machinery
LAPP Group™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
Need a cut length, bulk pricing, or a spec sheet?
Our team quotes custom lengths and volume orders, usually same day.
