LAPP Group 2212040, OLFLEX TRAY II CY 12 AWG 4C Shld 600V UL TC

Part Number: 2212040

LAPP Group 2212040 OLFLEX TRAY II CY is a Shielded, multi-Conductor tray Cable built for demanding industrial installations and tray wiring. It features 12 AWG 4-Conductor Construction with black Conductors with white printing plus green/yellow ground for clear Identification. Designed for 600V applications, it carries UL tray ratings including UL TC-ER, UL ITC-ER, and UL PLTC-ER for flexible installation options. The black thermoplastic polymer Jacket and PVC/Nylon Insulation support use in industrial plant expansions, automotive plants, and anywhere VNTC® cables are used.

Electrical & Ratings:

• Voltage Rating: 600V
• Tray ratings: UL ITC-ER, UL PLTC-ER, UL TC-ER
• UL style / standard: UL 13, UL 1063, UL 1277, UL 1690, UL 2250
• Standards: UL/CSA/CE
• RoHS compliant: Yes

Construction:

• Wire type: Multi-Conductor
• AWG/gauge: 12
• Number Of Conductors: 4
• Conductor Stranding: Stranded
• Conductor color: Black with white printing plus green/yellow ground
• Insulation: PVC/Nylon
• Shield: Shielded

Jacket & Dimensions:

• Jacket Material: Thermoplastic Polymer
• Jacket Color: Black
• Nominal OD (mm): 12.5

Temperature Ratings:

• Temperature Range: -13°F to +194°F -25°C to +90°C
• Dynamic Temperature Rating: -13°F to +221°F -25°C to +105°C

Applications:

• Industrial plant expansions
• Automotive plants
• Tray wiring
• Anywhere VNTC® cables are used

Part Number:

• Manufacturer: LAPP
• Manufacturer part number: 2212040

LAPP Group™ and all associated trademarks are the property of their respective owners.
