LAPP Group 2214070, OLFLEX TRAY II CY 14 AWG 7C Shielded 600V

Part Number: 2214070

LAPP Group 2214070 OLFLEX TRAY II CY is a Shielded, multi-Conductor tray Cable built for demanding industrial installations and expansions. It features 14 AWG 7C Stranded Conductors with PVC/Nylon Insulation and a black thermoplastic polymer Jacket designed for flexibility and easier pulling than standard tray cables. Rated 600V and approved for UL ITC-ER, UL PLTC-ER, and UL TC-ER, it can help reduce material and labor costs by eliminating the need for conduit in many exposed-run applications. This Cable is well-suited for industrial plant expansions, automotive plants, tray wiring, and anywhere VNTC® cables are used.

Electrical & Ratings:

• Voltage range: 600V
• Tray ratings: UL ITC-ER, UL PLTC-ER, UL TC-ER
• UL style / standard: UL 13, UL 1063, UL 1277, UL 1690, UL 2250
• Standards: UL/CSA/CE
• RoHS compliant: Yes

Construction:

• Wire type: Multi-Conductor
• AWG/gauge: 14
• Number Of Conductors: 7
• Conductor Stranding: Stranded
• Conductor Type: Finely Stranded
• Conductor Material: Bare Copper
• Insulation: PVC/Nylon
• Jacket Material: Thermoplastic Polymer
• Jacket Color: Black
• Shield: Shielded
• Nominal OD (mm): 12.5

Identification:

• Conductor color: Black with white printing plus green/yellow ground

Temperature:

• Temperature Range: -13°F to +194°F -25°C to +90°C
• Dynamic Temperature Rating: -13°F to +221°F -25°C to +105°C

Performance Features:

• Oil Resistant pressure extruded PVC Jacket for improved flexibility
• Easier to pull than standard tray cables to help minimize labor time
• UL TC-ER approval can help reduce overall material costs
• No conduit is needed
• Black numbered Conductors support fast, accurate Identification
• UV resistant and direct burial

Applications:

• Industrial plant expansions; automotive plants; tray wiring; anywhere VNTC® cables are used

Manufacturer Information:

• Manufacturer: LAPP
• Manufacturer part number: 2214070

LAPP Group™ and all associated trademarks are the property of their respective owners.
