LAPP Group 2216030, OLFLEX TRAY II CY 16 AWG 3C Shielded 600V

Part Number: 2216030

LAPP Group 2216030 OLFLEX TRAY II CY is a Shielded, multi-Conductor tray Cable built for demanding industrial environments and 600V applications. It features 16 AWG Stranded Conductors with PVC/Nylon Insulation and a black thermoplastic polymer Jacket designed for flexibility and easier pulling compared to standard tray cables. This Cable is suited for industrial plant expansions, automotive plants, tray wiring, and anywhere VNTC® cables are used. It carries UL ITC-ER, UL PLTC-ER, and UL TC-ER tray ratings and supports direct burial and UV-resistant installations.

Electrical & Construction:

• Manufacturer: LAPP
• Manufacturer part number: 2216030
• Attributes: Multi-Conductor
• Number Of Conductors: 3
• Wire size: 16 AWG
• Conductor Stranding: Stranded
• Shield: Shielded
• Voltage range: 600V

Materials & Colors:

• Insulation: PVC/Nylon
• Jacket Material: Thermoplastic Polymer
• Jacket Color: Black
• Conductor color: Black with white printing plus green/yellow ground

Dimensions & Temperature Ratings:

• Nominal OD (mm): 8.9
• Temperature Range: -13°F to +194°F -25°C to +90°C
• Dynamic Temperature Rating: -13°F to +221°F -25°C to +105°C

Approvals & Standards:

• Tray ratings: UL ITC-ER, UL PLTC-ER, UL TC-ER
• UL style / standard: UL 13, UL 1063, UL 1277, UL 1690, UL 2250
• Standards: UL/CSA/CE
• RoHS compliant: Yes

Features & Applications:

• Oil Resistant pressure extruded PVC Jacket for improved flexibility
• Easier to pull than standard tray cables to help reduce labor time
• UL TC-ER approval can help reduce overall material requirements
• No conduit is needed
• Black numbered Conductors for easy Identification
• UV resistant and direct burial
• Application: Industrial plant expansions; automotive plants; tray wiring; anywhere VNTC® cables are used
