LAPP Group 2216040, Flexible Control Cable 4C 600V PVC Foil+BRD SHD

Part Number: 2216040

LAPP 2216040 is a flexible, multi-Conductor Control Cable designed for 600V industrial tray and plant wiring applications. It features 4 Conductors of 16 AWG Stranded Bare Copper with PVC/Nylon Insulation for dependable performance in demanding environments. A black thermoplastic polymer Jacket and Shielded construction help support reliable signal integrity in industrial plant expansions, automotive plants, and tray wiring. Temperature performance is rated -13°F to +194°F (-25°C to +90°C), with a dynamic Temperature Rating of -13°F to +221°F (-25°C to +105°C).

Manufacturer Information:

• Manufacturer: LAPP
• Manufacturer part number: 2216040
• Attributes: Multi-Conductor
• Product type: TrayflexII

Conductors:

• Number Of Conductors: 4
• Conductor Size: 16 AWG
• Conductor Stranding: Stranded
• Conductor Material: Bare Copper
• Conductor color: Black with white printing plus green/yellow ground

Insulation & Jacket:

• Insulation: PVC/Nylon
• Jacket Material: Thermoplastic Polymer
• Jacket Color: Black
• Nominal OD (mm): 9.6

Shielding:

• Shield: Shielded

Electrical Ratings:

• Voltage range: 600V

Temperature Ratings:

• Temperature Range: -13°F to +194°F -25°C to +90°C
• Dynamic Temperature Rating: -13°F to +221°F -25°C to +105°C

Approvals & Standards:

• Tray ratings: UL ITC-ER UL PLTC-ER UL TC-ER
• UL style / standard: UL 13 UL 1063 UL 1277 UL 1690 UL 2250
• Standards: UL/CSA

Applications:

• Industrial plant expansions; automotive plants; tray wiring; anywhere VNTC® cables are used
