LAPP Group 2216070, OLFLEX TRAY II CY 16 AWG 7C Shielded 600V

Part Number: 2216070

LAPP Group 2216070 OLFLEX TRAY II CY is a 16 AWG 7-Conductor Shielded tray Cable rated 600V for demanding industrial installations. It features black Conductors with white printing plus green/yellow ground for fast, accurate Identification during termination. The Oil Resistant pressure extruded PVC Jacket is designed for improved flexibility and easier pulling than standard tray cables, helping reduce installation time. Built for industrial plant expansions, automotive plants, and tray wiring, it is also suitable anywhere VNTC® cables are used.

Key Features:

• Shielded construction for improved signal integrity in electrically noisy environments
• Oil Resistant pressure extruded PVC Jacket for improved flexibility
• Easier to pull than standard tray cables to help minimize labor costs
• UL TC-ER approval to help reduce material costs
• No conduit is needed
• Black numbered Conductors for easy Identification
• UV resistant and direct burial

Electrical:

• Voltage Rating: 600V

Conductors:

• Wire size: 16 AWG
• Number Of Conductors: 7
• Conductor Stranding: Stranded
• Conductor Type: Finely Stranded
• Conductor Material: Bare Copper
• Conductor color: Black with white printing plus green/yellow ground

Insulation & Jacket:

• Insulation: PVC/Nylon
• Insulation Material: PVC/NYL-POLYVINYL CHLORIDE/NYLON
• Jacket Color: Black
• Jacket Material: Thermoplastic Polymer
• Nominal OD (mm): 11.3

Temperature Ratings:

• Temperature Range: -13°F to +194°F -25°C to +90°C
• Dynamic Temperature Rating: -13°F to +221°F -25°C to +105°C

Ratings & Compliance:

• Tray ratings: UL ITC-ER UL PLTC-ER UL TC-ER
• UL style / standard: UL 13 UL 1063 UL 1277 UL 1690 UL 2250
• Standards: UL/CSA/CE
• RoHS compliant: Yes

Applications:

• Industrial plant expansions; automotive plants; tray wiring; anywhere VNTC® cables are used

Additional Attributes:

• Attributes: Multi-Conductor
• Product type: TRAYFLEXII
• Manufacturer part number: 2216070
