LAPP Group 2218030, OLFLEX TRAY II CY 18 AWG 3C Shielded 600V

Part Number: 2218030

LAPP Group 2218030 OLFLEX TRAY II CY is a Shielded, multi-Conductor tray Cable built for demanding industrial installations and plant expansions. It features 18 AWG 3-Conductor Construction with Stranded Conductors and black Conductors with white printing plus green/yellow ground for clear Identification. Designed for tray wiring and automotive plants, it carries 600V rating and UL ITC-ER, UL PLTC-ER, and UL TC-ER tray approvals to help reduce installation materials. The Oil Resistant pressure extruded Jacket improves flexibility and makes pulls easier than standard tray cables, and it is also UV resistant and suitable for direct burial.

Electrical & Construction:

• Manufacturer: LAPP
• Manufacturer part number: 2218030
• Product type: TrayflexII
• Attributes: Multi-Conductor
• Voltage range: 600V
• Number Of Conductors: 3
• Wire size: 18 AWG
• Conductor Stranding: Stranded
• Conductor Type: Finely Stranded
• Conductor Material: Bare Copper
• Shield: Shielded

Insulation, Jacket & Color:

• Insulation: PVC/Nylon
• Insulation Material: PVC/NYL-POLYVINYL CHLORIDE/NYLON
• Jacket Material: Thermoplastic Polymer
• Jacket Color: Black
• Conductor color: Black with white printing plus green/yellow ground
• Nominal OD (mm): 8.2

Temperature Ratings:

• Temperature Range: -13°F to +194°F -25°C to +90°C
• Dynamic Temperature Rating: -13°F to +221°F -25°C to +105°C

Approvals & Compliance:

• Tray ratings: UL ITC-ER UL PLTC-ER UL TC-ER
• UL style / standard: UL 13 UL 1063 UL 1277 UL 1690 UL 2250
• Standards: UL/CSA/CE
• RoHS compliant: Yes

Performance Features:

• Oil Resistant pressure extruded Jacket for improved flexibility
• Easier to pull than standard tray cables to help minimize labor time
• UL TC-ER approval can help reduce material costs
• No conduit is needed
• Black numbered Conductors for easy Identification
• UV resistant and direct burial

Applications:

• Industrial plant expansions; automotive plants; tray wiring; anywhere VNTC® cables are used

LAPP Group™ and all associated trademarks are the property of their respective owners.
