LAPP Group 2218070, Flexible Control Cable — 7C 18 AWG Shielded 600V PVC

Part Number: 2218070

LAPP Group 2218070 is a flexible, Shielded multi-Conductor Control Cable built for demanding industrial environments and tray wiring. It features 7 Conductors of 18 AWG Stranded Bare Copper with PVC/Nylon Insulation and a black thermoplastic polymer Jacket. Rated 600V and approved for UL ITC-ER, UL PLTC-ER, and UL TC-ER tray applications, it’s well-suited for industrial plant expansions, automotive plants, and anywhere VNTC® cables are used. The Cable supports a Temperature Range of -13°F to +194°F (-25°C to +90°C), with a dynamic Temperature Rating of -13°F to +221°F (-25°C to +105°C).

Part Number & Type:

• Manufacturer: LAPP
• Manufacturer Part Number: 2218070
• Attributes: Multi-Conductor
• Product Type: TrayflexII

Conductors:

• Number Of Conductors: 7
• Wire Size: 18 AWG
• Conductor Material: Bare Copper
• Conductor Stranding: Stranded
• Conductor Color: Black with white printing plus green/yellow ground

Insulation, Jacket & Dimensions:

• Insulation: PVC/Nylon
• Jacket Material: Thermoplastic Polymer
• Jacket Color: Black
• Nominal OD (mm): 10.1

Electrical & Shielding:

• Voltage Range: 600V
• Shield: Shielded

Temperature Ratings:

• Temperature Range: -13°F to +194°F -25°C to +90°C
• Dynamic Temperature Rating: -13°F to +221°F -25°C to +105°C

Approvals & Applications:

• Tray Ratings: UL ITC-ER UL PLTC-ER UL TC-ER
• UL Style / Standard: UL 13 UL 1063 UL 1277 UL 1690 UL 2250
• Standards: UL/CSA
• Application: Industrial plant expansions; automotive plants; tray wiring; anywhere VNTC® cables are used
