LAPP Group 2218180, Flexible Control Cable — 18 AWG 18C Shielded 600V PVC

Part Number: 2218180

LAPP 2218180 is a flexible, Shielded multi-Conductor Control Cable built for 600V industrial tray and plant wiring. It features 18 AWG Stranded Conductors with PVC/Nylon Insulation and a black thermoplastic polymer Jacket for durable performance in demanding environments. The Conductor Identification is black with white printing plus green/yellow ground, supporting organized terminations in control and automation panels. Designed for industrial plant expansions, automotive plants, and tray wiring, it carries UL ITC-ER, UL PLTC-ER, and UL TC-ER tray ratings with multiple UL standards.

Conductor & Construction:

• Manufacturer: LAPP
• Manufacturer part number: 2218180
• Attributes: Multi-Conductor
• AWG/gauge: 18
• Number Of Conductors: 18
• Conductor Stranding: Stranded
• Conductor Material: Bare Copper
• Conductor color: Black with white printing plus green/yellow ground
• Shield: Shielded

Materials & Dimensions:

• Insulation: PVC/Nylon
• Jacket Material: Thermoplastic Polymer
• Jacket Color: Black
• Nominal OD (mm): 15.7

Electrical & Temperature Ratings:

• Voltage range: 600V
• Temperature Range: -13°F to +194°F -25°C to +90°C
• Dynamic Temperature Rating: -13°F to +221°F -25°C to +105°C

Approvals, Tray Ratings & Standards:

• Tray ratings: UL ITC-ER UL PLTC-ER UL TC-ER
• UL style / standard: UL 13 UL 1063 UL 1277 UL 1690 UL 2250
• Standards: UL/CSA

Applications:

• Industrial plant expansions; automotive plants; tray wiring; anywhere VNTC® cables are used
