LAPP Group 2218250, Flexible Control Cable 18 25C Shielded 600V PVC

Part Number: 2218250

LAPP 2218250 is a flexible, Shielded multi-Conductor Control Cable built for 600V tray wiring in demanding industrial environments. It features 18 AWG Stranded Conductors with PVC/Nylon Insulation and a black thermoplastic polymer Jacket for durable performance. The black Conductors with white printing plus green/yellow ground support clear Identification during installation. Designed for industrial plant expansions, automotive plants, and anywhere VNTC® cables are used, it carries UL ITC-ER, UL PLTC-ER, and UL TC-ER tray ratings.

Manufacturer Information:

• Manufacturer: LAPP
• Manufacturer Part Number: 2218250
• Attributes: Multi-Conductor

Electrical:

• Voltage Range: 600V

Conductors:

• AWG/Gauge: 18
• Number Of Conductors: 25
• Conductor Type: Stranded
• Conductor Material: Bare Copper
• Conductor Color: Black with white printing plus green/yellow ground

Shielding:

• Shield: Shielded
• Shield Type: Foil Shield AL Mylar

Materials & Construction:

• Insulation: PVC/Nylon
• Jacket Material: Thermoplastic Polymer
• Jacket Color: Black
• Nominal OD (mm): 17.7

Temperature Ratings:

• Temperature Range: -13°F to +194°F -25°C to +90°C
• Dynamic Temperature Rating: -13°F to +221°F -25°C to +105°C

Approvals & Standards:

• Tray Ratings: UL ITC-ER, UL PLTC-ER, UL TC-ER
• UL Style / Standard: UL 13, UL 1063, UL 1277, UL 1690, UL 2250
• Standards: UL/CSA

Applications:

• Industrial plant expansions
• Automotive plants
• Tray wiring
• Anywhere VNTC® cables are used
