LAPP Group 301802, Flexible Signal Control Cable 2C 18 AWG PVC Unshielded

Part Number: 301802

LAPP UNITRONIC® 300 / 300S 301802S is a flexible, multi-Conductor signal and Control Cable designed for reliable routing in industrial control and process instrumentation applications. It features 2 Conductor of 18 AWG Tinned Copper with a Stranded construction for easier installation in tight pathways. A durable gray PVC Jacket supports use in Cable tray and provides Oil Res I and UV resistance. Rated 300V with a nominal OD (MM) of 6.8, this Unshielded Cable is well-suited for low voltage control interconnects where EMC shielding is not required.

Conductor & Construction:

• Series: UNITRONIC® 300 / 300S
• Attributes: Multi-Conductor
• Number Of Conductors: 2 Conductor
• AWG/Gauge: 18
• Conductor Size: 18 AWG
• Conductor Material: Tinned Copper
• Conductor Material (Alt. Listing): Tinned Or Coated Copper
• Conductor Stranding: Stranded
• Conductor Type: Finely Stranded
• Earth/Ground Wires: No

Insulation & Jacket:

• Insulation Material: PVC Polyvinyl Chloride
• Jacket Material: PVC
• Jacket Material (Alt. Listing): PVC Polyvinyl Chloride
• Jacket Color: Gray
• Nominal OD (MM): 6.8

Electrical & Shielding:

• Voltage: 300V
• Voltage Range: 300V OR 300/500V
• Shield: Unshielded

Ratings, Standards & Performance:

• Standards: UL/CSA/CE
• Extended Temperature Rating: -25oC to +105oC
• Flexibility: Flexible
• Suitable for use in Cable tray
• Oil and UV resistant (Oil Res I)
• Sequential foot Marking for ease of installation

Applications:

• Industrial signal and control applications
• Process Instrumentation
• Low Voltage control interc onnect

Product Identification:

• Manufacturer: LAPP
• Manufacturer Part Number: 301802S
• Product Type: UNITRONIC
