LAPP Group 601603, Control Power Cable 3C 16 AWG Unshielded PVC

Part Number: 601603

LAPP 601603 is a flexible multi-Conductor control and power Cable built for industrial equipment in dry, damp, and wet conditions. It features a highly oil-, coolant-, and solvent-resistant PVC Jacket and is designed for reliable routing and termination in machinery and control panels. This 3C 16 AWG Unshielded Cable includes black Conductors with white printing plus a green/yellow ground, and it carries UL TC-ER tray ratings. It is rated for -13°F to +194°F -25°C to +90°C and supports demanding industrial applications such as CNC machining centers, conveyors, and processing equipment.

Key Features & Applications:

• Excellent industrial control and power Cable for machinery and equipment wiring
• Extremely Oil Resistant (Oil Res I & II)
• Meets NFPA79 2007 machinery wiring standard
• Very flexible and number coded for easier routing and termination
• Round Jacket design helps provide an optimal seal with a SKINTOP Strain Reli
• Common uses: CNC machining centers, grinding machines, bottling equipment, conveyors, processing equipment, assembly lines, and controlpanels
• Designed for use in electrical equipment in dry, damp, and wet conditions

Electrical & Standards:

• Voltage range: 600V
• Tray ratings: UL TC-ER
• UL style / standard: UL 13 UL 2277
• Standards: UL/CSA/CE
• RoHS compliant: Yes

Construction:

• Attributes: Multi-Conductor
• Number Of Conductors: 3
• AWG/gauge: 16
• Conductor Stranding: Stranded
• Conductor Type: Finely Stranded
• Conductor Material: Bare Copper
• Shield: Unshielded
• Conductor color: Black with white printing plus green/yellow ground

Jacket, Insulation & Dimensions:

• Insulation: PVC
• Insulation Material: PVC-Polyvinyl Chloride
• Jacket Material: Thermoplastic Polymer
• Jacket Color: Gray
• Nominal OD (mm): 8.1

Temperature & Ratings:

• Temperature: -13°F to +194°F -25°C to +90°C
• Dynamic Temperature Rating: -13°F to +194°F -25°C to +90°C

Additional Details:

• Manufacturer: LAPP
• Manufacturer part number: 601603
• Product type: Flex Cont
• Weight lbs/mft: 62
