LAPP Group 602002, OLFLEX 190 Flexible Cable 2C 20 AWG 600V

Part Number: 602002

LAPP OLFLEX 190 602002 is a flexible 2-Conductor 20 AWG control and power Cable designed for industrial equipment in dry, damp, and wet conditions. It features a rugged thermoplastic polymer Jacket and PVC Insulation, with a gray Outer Jacket and black Conductors with white printing plus green/yellow ground Identification. Built for demanding machinery environments, it offers strong resistance to oil, coolant, and solvents and supports easy routing and termination with its flexible, number-coded design. Rated 600V and -13°F to +194°F -25°C to +90°C, it carries UL PLTC-ER and UL TC-ER tray ratings and meets NFPA79 2007 machinery wiring requirements.

Manufacturer & Part Number:

• Manufacturer: LAPP
• Manufacturer part number: 602002
• Series: OLFLEX 190

Electrical & Standards:

• Voltage range: 600V
• Tray ratings: UL PLTC-ER, UL TC-ER
• UL style / standard: UL 13, UL 2277
• Standards: UL/CSA
• RoHS compliant: Yes
• Meets NFPA79 2007 machinery wiring standard

Construction:

• Attributes: Multi-Conductor
• Number Of Conductors: 2
• Wire size: 20 AWG
• Conductor Stranding: Stranded
• Conductor Material: Bare Copper
• Conductor color: Black with white printing plus green/yellow ground
• Insulation: PVC
• Jacket Material: Thermoplastic Polymer
• Jacket Color: Gray
• Shield: Unshielded
• Nominal OD (mm): 6.4
• Product type: Flex cont

Temperature & Environmental:

• Temperature: -13°F to +194°F -25°C to +90°C
• Dynamic Temperature Rating: -13°F to +194°F -25°C to +90°C
• Extremely Oil Resistant (Oil Res I & II)
• Designed for use in dry, damp and wet conditions

Applications & Key Features:

• Excellent industrial power and Control Cable
• Very flexible and number coded for easier routing and termination
• Round Jacket for optimal seal with a SKINTOP Strain Reli
• For machinery: CNC machining centers, grinding machines, bottling equipment, conveyors, processing equipment, assembly lines and controlpanels

Weight:

• Weight lbs/mft: 40
