LAPP Group 8916034, OLFLEX FD 890 Continuous Flex Cable 16 AWG 3C 600V

Part Number: 8916034

LAPP 8916034 OLFLEX FD 890 is a continuous-flex Control Cable built for demanding motion applications where durability and long service life matter. It features 16 AWG Stranded Conductors in a 3-Conductor, Unshielded construction with a PVC Jacket and PVC Polyvinyl Chloride Insulation. Rated 600V and designed to perform from 23°F to +194°F (-5°C to +90°C), it also meets Oil Res I/II for use in oily industrial environments. A pressure-extruded Jacket supports precise connectorization, and the Cable passes UL 1277 impact and crush tests.

Key Features:

• Meets Oil Res I/II
• Resistant to harsh environments for long service life
• Pressure-extruded Jacket for precision connectorization
• Passes UL 1277 impact and crush tests

Electrical:

• Voltage: 600V

Construction:

• AWG/gauge: 16
• Number Of Conductors: 3
• Conductor Stranding: Stranded
• Conductor Material: Bare Copper
• Shielding: Unshielded
• Earth/ground wires: No

Materials:

• Insulation Material: PVC Polyvinyl Chloride
• Jacket Material: PVC

Dimensions:

• Nominal OD (in): 0.323

Temperature Rating:

• 23°F to +194°F
• -5°C to +90°C

Compliance & Standards:

• Standards: UL/CSA/CE
• RoHS compliant: Yes

Product Identification:

• Manufacturer: LAPP
• Manufacturer part number: 8916034
• Product type: FLEX CONT
