LAPP Group 8918034, OLFLEX FD 890 Continuous Flex Cable 18 AWG 3C 600V

Part Number: 8918034

LAPP 8918034 OLFLEX FD 890 is a Continuous Flex Control Cable built for demanding motion applications where durability and consistent performance matter. It features 18 AWG Stranded Conductors in a 3 Conductor, Unshielded construction with a PVC Jacket designed for long service life in harsh environments. Rated 600V and tested to pass UL 1277 impact and crush requirements, it also meets Oil Res I/II for added resistance in industrial settings. The pressure-extruded Jacket supports precise connectorization, and the Cable is RoHS compliant for broader compliance needs.

Electrical & Compliance:

• Voltage: 600V
• Standards: UL/CSA/CE
• RoHS compliant: Yes

Construction:

• Wire gauge: 18 AWG
• Number Of Conductors: 3
• Conductor Stranding: Stranded
• Conductor Material: Bare Copper
• Shielding: Unshielded
• Earth/ground wires: No

Materials & Dimensions:

• Insulation Material: PVC-Polyvinyl Chloride
• Jacket Material: PVC
• Nominal OD (in): 0.287

Temperature Rating:

• Temperature: 23°F to +194°F -5°C to +90°C

Performance Features:

• Meets Oil Res I/II
• Designed to withstand harsh environments for extended service life
• Pressure-extruded Jacket supports precision connectorization
• Passes UL 1277 impact and crush tests

Product Identification:

• Manufacturer: LAPP
• Manufacturer part number: 8918034
• Product type: Flex cont
