Panduit C100X050APT, Thermal Transfer Raised Panel Label 1 x 0.5 in. White

Panduit C100X050APT is a thermal transfer component label for raised panel surfaces, 1 in. x 0.5 in. (25.4mm x 12.7mm), in white. The printable face takes crisp, durable legends from Panduit thermal transfer resin ribbons, and the high-tack adhesive holds on the textured and slightly irregular surfaces that shed a general purpose label. The GMH3-W stock is tested to ASTM G154 for weathering and ASTM D3389 for abrasion and meets DIN 40050-9 IP69K, so a printed legend survives washdown, handling and outdoor exposure. Labels are carried three to a row and format directly in Easy-Mark Plus labeling software.

Panduit C100X050APT Technical Specs

Product Classification

Product type	Component label
Application surface	Raised panel
Print method	Thermal transfer
Category	Labels

Materials & Adhesive

Material	GMH3-W
Adhesive	High tack
Printable surface	Yes

Dimensions

Width	1 in. (25.4mm)
Height	0.5 in. (12.7mm)
Labels per row	3

Color

Color	White

Printing & Software

Ribbon	Panduit thermal transfer resin ribbon
Software	Easy-Mark Plus labeling software

Compliance & Certifications

UL	UL969 Recognized
cUL	Recognized
Weathering	ASTM G154
Abrasion	ASTM D3389
Ingress protection	DIN 40050-9, IP69K
RoHS Compliant	Compliant
UNSPSC code	55120000

Packaging

Sold as	Each

Panduit C100X050APT Applications

• Identifies breakers, switches and components on raised or textured panel faces inside an enclosure.
• Marks control gear in washdown areas, where the IP69K rating keeps the legend on the label.
• Labels outdoor and sunlit equipment that would fade a general purpose printed label.
• Runs sequential component legends off a thermal transfer printer straight from Easy-Mark Plus.
