Panduit CFPE10BL-2GY, Black ABS Flush Faceplate, 2 Gang, 10 Port, 4.5 in.

Panduit CFPE10BL-2GY is a Pan-Net® Mini-Com® faceplate for flush-mount multimedia outlet installations, organizing and protecting up to 10 ports. It supports Mini-Com Modules for UTP, STP, Fiber-Optic, and A/V connectivity to help deliver a clean, professional finish. Its horizontal mount orientation and flat outlet orientation help maintain a neat, consistent appearance. Port identification is supported through an adhesive label system that includes a label and cover for clear port marking.

Panduit CFPE10BL-2GY Technical Specs

Product Classification & Configuration

Product type	Faceplate
Type	Multimedia Outlet
Sub brand	Pan-Net®
Module type	Mini-Com®
Number of ports	10
Port configuration	Mini-Com Modules, UTP, STP, Fiber-Optic, A/V
Loaded	No

Mounting & Orientation

Mounting	Flush-mount
Mount orientation	Horizontal
Outlet orientation	Flat

Dimensions

Size	LxDxW: 4.5 x 0.83 x 4.5 in.
Overall height (in.)	4.5
Overall height (mm)	114.3
Overall width (in.)	4.6
Overall width (mm)	116.84
Overall depth (in.)	0.76
Overall depth (mm)	19.3

Materials, Color & Identification

Material	Stainless Steel
Color	Metallic
Identification type	Adhesive Label
Labeling	Label and Cover

Compliance & Certifications

Standards met	RoHS Compliant

Packaging & Logistics

UPC	07498303285
Standard package quantity	1
Standard package volume (cu. ft.)	0.0160
Standard carton quantity	10
Standard carton volume (cu. ft.)	0.1604

Panduit CFPE10BL-2GY Applications

• Supports multimedia outlet applications that bring multiple connectivity types to a single, organized wall location using Mini-Com Modules for UTP, STP, Fiber-Optic, and A/V.
• Helps maintain a clean, flush-mount installation that keeps ports organized and protected in work areas.
• Works well in installations that benefit from a horizontal mount orientation and flat outlet orientation for a neat, consistent finish.
• Provides clear port marking using an adhesive label system with a label and cover for identification.
