Panduit FSD78-8-DSL0, Insulated Ferrule 16 AWG Black, On Strip

Panduit FSD78-8-DSL0 is a Pan-Term covered single-wire ferrule supplied on a continuous strip, so a strip-fed crimp tool can terminate lead after lead without an operator hand-loading each sleeve. The seamless barrel closes around the stripped conductor and holds loose strands captive for a clean termination, while the flared plastic covering opens the mouth of the ferrule and makes wire insertion faster. Finished leads push straight into a terminal block, which matters in crowded panels where a bare stranded end would splay. It is 16 AWG in black with a 13/32 in. strip length.

Panduit FSD78-8-DSL0 Technical Specs

Product Classification

Product type	Wire ferrule (end sleeve)
Style	Covered single wire ferrule
Presentation	On strip
Wires per ferrule	Single
Seamless barrel	Yes

Conductor & Sizing

Contact material	Copper
Wire size	16 AWG
Strip length	13/32 in.
Wire entry	Flared plastic covering

Color & Identification

Color	Black

Compliance & Certifications

DIN 46228	Yes
CSA C22.2 no. 291-14	Yes
UL 486F	Yes
UNSPSC code	39121400

Packaging

Sold as	Each

Panduit FSD78-8-DSL0 Applications

• Feeds strip-fed crimp tools on panel shop benches where hundreds of leads are terminated per build.
• Terminates stranded control wire entering screw or spring-cage terminal blocks.
• Keeps loose strands contained on leads that get removed and re-landed during service work.
• Suits shallow enclosures where a bare stranded end would not seat cleanly in the block.
