Panduit FZTBN1NNNSZM001, OM4 LC Pigtail 900um 1 m, Set of 12

Panduit FZTBN1NNNSZM001 is a set of twelve OM4 pigtails, each a single 900um tight-buffered fiber with an LC connector factory terminated on one end and the far end left bare for splicing. Fusion splicing pigtails into a tray is how most field cables get their connectors, and a factory-polished LC end gives a repeatable loss figure that on-site termination struggles to match. The twelve buffer colors follow the EIA/TIA 568 order, so each strand lands on the port it belongs to. There is no jacket over the buffer, and each pigtail is 1 meter long.

Panduit FZTBN1NNNSZM001 Technical Specs

Product Classification

Product type	Fiber optic pigtail
Assembly type	Pigtail, one end terminated
Fibers per pigtail	1 fiber
Fiber mode	Multimode

Fiber & Performance

Fiber type	OM4 laser-optimized multimode
Insertion loss grade	Standard IL
Buffer	900um tight buffered

Connectors

Connector, terminated end	LC
Far end	Unterminated, for fusion or mechanical splicing

Materials & Construction

Jacket	None - 900um buffered fiber
Jacketed	No

Color & Identification

Buffer colors	12-color set per EIA/TIA 568
Color coded	Yes

Dimensions

Length	1 m (3.3 ft.) per pigtail

Packaging

Pigtails per set	12
Sold as	Each - one set of 12
UNSPSC code	26121650

Panduit FZTBN1NNNSZM001 Applications

• Terminates a 12-strand field cable in a splice tray, one pigtail fusion spliced to each buffered strand.
• Restores a damaged fiber run without re-pulling cable, by splicing a new connectorized end into the tray.
• Keeps strand identity correct through a splice enclosure, since the buffer colors follow the standard 12-color order.
• Suits work where a factory-polished connector is required and field polishing is not acceptable.
