Panduit LCC6-56BW-L, 2-Hole Lug #6 AWG, 5/16 in. Stud .75 in. Centers
SKU:LCC6-56BW-L
● In stock
ea
Description
Panduit LCC6-56BW-L is a two-hole, long-barrel copper compression lug that terminates #6 AWG conductor on 5/16 in. studs spaced 0.75 in. apart. The larger stud hole suits bus bars and equipment pads fitted with 5/16 in. hardware, where a 1/4 in. lug would sit loose on the bolt. Its long barrel accepts the maximum number of crimps for premium pull-out strength and electrical performance, and the inspection window lets the installer confirm the conductor is fully inserted before crimping. The tin-plated copper body resists corrosion and the blue color-coded barrel carries Panduit and specified competitor die index numbers.
Panduit LCC6-56BW-L Technical Specs
Product Classification
| Product type | Compression lug |
|---|---|
| Lug style | Standard compression |
| Barrel | Long barrel |
| Number of bolt holes | 2 hole |
| Inspection window | Yes |
Conductor & Termination
| Conductor size | #6 AWG |
|---|---|
| Conductor Material | Copper |
| Stud hole size | 5/16 in. |
| Hole spacing | 0.75 in. on center |
Materials & Finish
| Lug material | Copper |
|---|---|
| Plating | Tin |
| Barrel color code | Blue |
| Die index marking | Panduit and specified competitor die index numbers |
Electrical & Temperature Ratings
| Voltage Rating | Up to 35 kV, UL Listed and CSA Certified |
|---|---|
| Temperature rating | 90°C (194°F) |
| Rating condition | When crimped with Panduit or specified competitor tools and dies |
| Wide wire range-taking | UL Listed and CSA Certified with Panduit Uni-Die dieless crimping tools |
Compliance & Certifications
| UL listed | Yes |
|---|---|
| CSA certified | Yes |
| NEBS level 3 | Tested by Telcordia |
| J-STD-607-A | Meets requirements |
| TIA-942 | Meets network systems grounding requirements |
| RoHS Compliant | Yes |
| UNSPSC code | 39121400 |
Packaging
| Sold as | Each |
|---|
Panduit LCC6-56BW-L Applications
- Terminates #6 AWG bonding conductors on bus bars and equipment pads drilled for 5/16 in. hardware.
- Lands grounding conductors at switchgear and motor control centers where 5/16 in. studs are the site standard.
- Bonds racks, cabinets and cable runway to a telecommunications ground bar under J-STD-607-A.
- Gives a two-bolt, non-rotating connection on high-vibration equipment where a single stud could loosen.
Panduit™ and all associated trademarks are the property of their respective owners.
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
